Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 26" -
Groupset GX, Deore -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Big Dummy, Surly 4130 Chromoly steel. Surly Big Dummy, Surly 4130 Chromoly steel. Main triangle double-butted. TIG-welded cargo specific engineered for stiffness.
Suspension Fork
Surly Troll, TIG-welded 4130 Chromoly, Surly Troll 420mm axle-to-crown x 43mm offset, tapered and butted straight blade, 4130 Chromoly. 51mm I.S. disc mount
Drivetrain
Rear Derailleur
SRAM GX Type 2.1
Front Derailleur
Shimano Deore, FD-T611-3
Shift Levers
X5 Trigger
Cassette
Microshift CS-H100 10 speed, 11-36t
Crank
TruVativ 48/36/26
Bottom Bracket
SRAM
Chain
KMC X10
Wheels
Front Hub
Shimano Deore M525, 36h, QR
Rear Hub
Shimano Deore M525, 36h, QR
Rims
Alex Adventurer
Tires
Schwalbe Big Apple 26" x 60mm
Brakes
Brakes
Avid BB7
Brake Levers
Avid FR-5
Disk Rotors
SRAM Centerline 180/180mm
Cockpit
Stem
4 Bolt 31.8mm clamp
Handlebar
Premetec
Headset
Cane Creek 40
Seat
Saddle
WTB Volt Sport
Seatpost
2 -Bolt. 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.38 mm | 1.37 mm | 1.37 mm |
| Front Center | 611 mm | 634 mm | 652 mm | 670 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 64 mm | 64 mm | 64 mm | 64 mm |
| Stack | 572.9 mm | 586.4 mm | 600.5 mm | 617.7 mm |
| Reach | 406 mm | 424.5 mm | 438.1 mm | 450.5 mm |
| Top Tube Length | 579.9 mm | 602.5 mm | 620.5 mm | 638.2 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406.4 mm | 457.2 mm | 508 mm | 558.8 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 131.7 mm | 145.9 mm | 160.8 mm | 178.8 mm |
| Chainstay Length | 833 mm | 833 mm | 833 mm | 833 mm |
| Wheelbase | 1442 mm | 1465 mm | 1483 mm | 1501 mm |
| Bottom Bracket Drop | 40 mm | 40 mm | 40 mm | 40 mm |
| Standover Height | 746 mm | 777 mm | 809 mm | 842 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Big Dummy completes the Surly Big Dummy model. Surly released 12 bikes variations of this model so far. You can easily view all of the Surly Big Dummy bikes models from 2020, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Long Tail Cargo bikes average price
If you want to purchase a solid Long Tail Cargo bike, it is important to know that the average cost is 1276$. However, this doesn’t mean that if you spend less money on a Long Tail Cargo bike, you couldn’t get a decent one. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
This bike was released in 2020 and its price was 2150$. If we compare this with the average Long Tail Cargo bike cost we notice that the price is 68.5% higher.
Big Dummy components
Fork material
Big Dummy has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
When leaving the production line, the Big Dummy model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Surly Big Dummy is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, with hydraulic disk brakes, you have the ultimate braking power!
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
