Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Bridge Club
Suspension Fork
Surly Bridge Club
Drivetrain
Rear Derailleur
Shimano Deore M5100 Shadow Plus
Front Derailleur
N/A
Shift Levers
Shimano Deore SL-M5100-R
Cassette
Shimano Deore CSM5100 11-51t
Crank
Shimano Deore M5100 32t
Bottom Bracket
Shimano BSA
Chain
KMC X11 EPT
Wheels
Front Hub
Novatec 9x100 QR
Rear Hub
Novatec 9x141 QR 11-spd
Tires
Surly Extraterrestrial 700x41, 60tpi Tubeless Ready
Brakes
Brakes
Tektro HD-M275
Brake Levers
Tektro HD-M275
Cockpit
Stem
Promax, 31.8mm
Handlebar
Surly Terminal Bar, XS,S - 718mm, M,L,XL - 735m
Headset
Cane Creek 40
Seat
Saddle
WTB Volt 142
Seatpost
Promax, 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.42 mm | 1.37 mm | 1.35 mm | 1.37 mm |
| Bottom Bracket Height | 289 mm | 289 mm | 289 mm | 289 mm | 289 mm |
| Front Center | 604 mm | 620 mm | 645 mm | 665 mm | 681 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 81 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Stack | 556.6 mm | 570.6 mm | 579.6 mm | 593.6 mm | 612.6 mm |
| Reach | 379.6 mm | 400.6 mm | 422.6 mm | 438.1 mm | 447.6 mm |
| Top Tube Length | 548.6 mm | 573.6 mm | 598.6 mm | 618.6 mm | 633.6 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 335.6 mm | 406.4 mm | 457.2 mm | 508 mm | 558.8 mm |
| Head Tube Angle | 70 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 145 mm | 165 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1035 mm | 1051 mm | 1076 mm | 1096 mm | 1112 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 712 mm | 754 mm | 783 mm | 815 mm | 849 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Bridge Club Frameset is a Surly Bridge model. There are 9 frames that carry this model name. Take a sneak peek at all Surly Bridge frames models from 2023, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel frames
If you want to purchase a solid Gravel frame, it is important to know that the average cost is 1505$. However, even if your budget is less than the average, you might still be able to get a top-quality Gravel frame. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2023 for 599$. If we compare this with the average Gravel frame cost we notice that the price is 151.25% lower.
Bridge Club Frameset components
Brakes
When you want to stop the bike in time, the brakes are vital. The Bridge Club Frameset has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
This frame is available in 5 sizes. They vary from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, you can easily find one that suits you.
