Surly Bridge Club Whipped Butter – 27.5 2023
2023 Road
Estimate price |
1,499$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Groupset CUES, Shimano -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
XS
156cm - 166cm
SM
163cm - 174cm
SM
163cm - 174cm
MD
171cm - 182cm
MD
171cm - 182cm
LG
179cm - 189cm
LG
179cm - 189cm
XL
185cm - 195cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Bridge Club, 100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Suspension Fork
Surly Bridge Club, 100% Surly Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
Drivetrain
Rear Derailleur
Shimano Cues
Front Derailleur
N/A
Shift Levers
Shimano Cues
Cassette
Shimano Cues, 11-50t, 11-speed
Crank
Shimano Cues, 32t
Chain
KMC
Wheels
Front Hub
Novatec 9x100mm QR, 6-bolt disc
Rear Hub
Novatec 10x141mm QR, 6-bolt disc
Rims
WTB ST i29 TCS, 32h
Tires
WTB Trail Boss 27.5 x 2.4", 27tpi, wire bead
Brakes
Brakes
Tektro Hydraulic
Cockpit
Stem
Promax, 31.8mm
Handlebar
Salsa Bend, XS,S - 718mm, M,L,XL - 735m
Grips
Velo Black
Headset
Cane Creek 40 Series, 1-1/8" Threadless
Seat
Saddle
WTB Volt
Seatpost
Promax 27.2 x 350mm, 12mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | XS | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.47 mm | 1.42 mm | 1.42 mm | 1.37 mm | 1.37 mm | 1.35 mm | 1.35 mm | 1.37 mm | 1.37 mm |
| Front Center | 604 mm | 604 mm | 620 mm | 620 mm | 645 mm | 645 mm | 665 mm | 665 mm | 681 mm | 681 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 74 mm | 74 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Stack | 556.6 mm | 556.6 mm | 570.6 mm | 570.6 mm | 579.6 mm | 579.6 mm | 593.6 mm | 593.6 mm | 612.6 mm | 612.6 mm |
| Reach | 379.6 mm | 379.6 mm | 400.6 mm | 400.6 mm | 422.6 mm | 422.6 mm | 438.1 mm | 438.1 mm | 447.6 mm | 447.6 mm |
| Top Tube Length | 548.6 mm | 548.6 mm | 573.6 mm | 573.6 mm | 598.6 mm | 598.6 mm | 618.6 mm | 618.6 mm | 633.6 mm | 633.6 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 335.6 mm | 335.6 mm | 406.4 mm | 406.4 mm | 457.2 mm | 457.2 mm | 508 mm | 508 mm | 558.8 mm | 558.8 mm |
| Head Tube Angle | 70 ° | 70 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° | 71 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 130 mm | 130 mm | 145 mm | 145 mm | 165 mm | 165 mm |
| Chainstay Length | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm | 438 mm |
| Wheelbase | 1035 mm | 1035 mm | 1051 mm | 1051 mm | 1076 mm | 1076 mm | 1096 mm | 1096 mm | 1112 mm | 1112 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 712 mm | 712 mm | 754 mm | 754 mm | 783 mm | 783 mm | 815 mm | 815 mm | 849 mm | 849 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 156 cm | 163 cm | 163 cm | 171 cm | 171 cm | 179 cm | 179 cm | 185 cm | 185 cm |
| Rider Max Height | 166 cm | 166 cm | 174 cm | 174 cm | 182 cm | 182 cm | 189 cm | 189 cm | 195 cm | 195 cm |
Model Overview
Bridge Club Whipped Butter – 27.5 belongs to the Surly Bridge model. 10 bikes variations carry this model name so far. You can get a glimpse at all models from 2023, by clicking on this link.
Model range prices
Surly Bridge Club 2023 is the cheapest bike model and costs 1499$. Surly Bridge Club Whipped Butter – 27.5 2023 is the most expensive one and costs 1499$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
At the moment of the release date, Surly Bridge Club Whipped Butter – 27.5 price was 1499$. In conclusion, this bike price is 64.24% smaller than the price of the average Gravel bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
As for the wheels, Surly Bridge Club Whipped Butter – 27.5 2023, has a aluminum model. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Bridge Club Whipped Butter – 27.5 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Bridge Club Whipped Butter – 27.5 comes in 10 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
