Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Groupset Deore, Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Cross-Check, Surly 4130 CroMoly steel. Main triangle double-butted. TIG-welded
Suspension Fork
Surly Cross-Check, 4130 CroMoly, lugged & brazed. Sloping crown w/threaded eyelets, tapered & butted curved blades w/mid-blade rack eyelets, dual dropout eyelets
Drivetrain
Rear Derailleur
Shimano Deore T610-SGS
Front Derailleur
Shimano Tiagra 4600
Shift Levers
Microshift BS-M10, bar-end shifter
Cassette
Shimano CS-HG50-10, 11-32, 10-speed
Crank
Shimano CX50, 36/46t
Bottom Bracket
68mm wide, standard English threaded 1.37? x 24t
Chain
KMC X10
Wheels
Front Hub
Shimano Deore T610, 32h, 100mm, black w/QR
Rear Hub
Shimano Deore T610, 32h, 135mm, black w/QR
Rims
Alex Adventurer 2
Spokes
DT Swiss Champion, 14g
Tires
Surly Knard, 700c x 41mm, 27 tpi
Brakes
Brakes
Tektro M730 V-Brake
Brake Levers
Tektro CL520
Cockpit
Stem
HL 31.8
Handlebar
Salsa Cowbell 3
Headset
Cane Creek Custom 5
Seat
Saddle
WTB Volt Sport, steel rails
Seatpost
Kalloy 368 non-offset (42–50cm), Kalloy 342 offset (52–64cm) 27.2 x 300mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 46cm | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm | 64cm |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.38 mm | 1.35 mm | 1.35 mm | 1.36 mm | 1.41 mm | 1.44 mm | 1.45 mm | 1.49 mm | 1.48 mm |
| Front Center | 579 mm | 581 mm | 589 mm | 590 mm | 598 mm | 603 mm | 614 mm | 628 mm | 638 mm | 658 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm | 67 mm |
| Stack | 531 mm | 531 mm | 531 mm | 531 mm | 541.4 mm | 559.5 mm | 578.7 mm | 596.6 mm | 615.7 mm | 633.9 mm |
| Reach | 381.7 mm | 383.8 mm | 392.1 mm | 392.7 mm | 397.8 mm | 397.3 mm | 401.3 mm | 410.3 mm | 414 mm | 427.5 mm |
| Top Tube Length | 525 mm | 531.8 mm | 544.8 mm | 550.1 mm | 563 mm | 573 mm | 583 mm | 603 mm | 613 mm | 633 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72.5 ° | 72.5 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 420 mm | 460 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm | 600 mm | 620 mm | 665 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 91 mm | 91 mm | 91 mm | 91 mm | 102 mm | 121 mm | 141 mm | 160 mm | 180 mm | 200 mm |
| Chainstay Length | 423 mm | 423 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm | 428 mm |
| Wheelbase | 992 mm | 994 mm | 1008 mm | 1008 mm | 1017 mm | 1022 mm | 1032 mm | 1047 mm | 1057 mm | 1077 mm |
| Bottom Bracket Drop | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm | 66 mm |
| Standover Height | 734 mm | 753 mm | 771 mm | 781 mm | 796 mm | 813 mm | 832 mm | 850 mm | 869 mm | 888 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
Cross-Check is a Surly Cross Check model. 12 bikes variations carry this model name so far. You can easily view all of the Surly Cross Check bikes models from 2017, here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Commuter bikes average price
If you want an acceptable Commuter bike you should know that the average price is 762$. However, this doesn’t mean that if you spend less money on a Commuter bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
Cross-Check has a steel fork, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
The wheels on Cross-Check are the 700c aluminum type. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
