Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Groupset SLX, Race Face -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Ice Cream Truck, 100% Surly 4130 Chromoly steel. Surly Ice Cream Truck, 100% Surly 4130 Chromoly steel. ED coated. Triple-butted main triangle. TIG-welded
Suspension Fork
Surly Ice Cream Truck, 1-1/8" straight steerer with tapered straight blade. Surly Ice Cream Truck, 1-1/8" straight steerer with tapered straight blade, 4130 Chromoly. 483mm axle to crown, 47mm offset. 51mm IS front standard disc mount. 150mm x 15mm thru axle dropouts (axle included).
Drivetrain
Rear Derailleur
Shimano SLX RD-M7100 12-Speed
Front Derailleur
N/A
Shift Levers
Shimano SLX SL-M7100
Cassette
Shimano SLX CS-M7100 10-51t, 12-Speed
Crank
Race Face AEffect with DM30t Steel Ring
Bottom Bracket
Race Face 100mm
Chain
KMC X12 NP/BK
Wheels
Front Hub
150x15mm, Novatec, 32h, Thru-Axle
Rear Hub
197x12mm, Novatec, 32h, Thru-Axle, with Shimano Microspline freehub
Rims
Surly My Other Brother Darryl, 80mm with speedholes
Tires
Surly Bud & Lou, 4.8", 120tpi, Tubeless Ready
Brakes
Brakes
Tektro Gemini HD-M520
Brake Levers
Tektro Gemini HD-M520
Disk Rotors
Tektro, 180/160
Cockpit
Stem
Promax, 31.8mm
Handlebar
Salsa Rustler without logo
Headset
Cane Creek 40
Seat
Saddle
WTB Volt 142
Seatpost
2-bolt 30.9mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.452 mm | 1.4 mm | 1.352 mm | 1.305 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 672 mm | 698 mm | 724 mm | 749 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 88 mm | 88 mm | 88 mm | 89 mm |
| Stack | 588 mm | 598 mm | 607 mm | 616 mm |
| Reach | 405 mm | 427 mm | 449 mm | 472 mm |
| Top Tube Length | 585 mm | 610 mm | 635 mm | 660 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 366 mm | 419 mm | 470 mm | 521 mm |
| Head Tube Angle | 68 ° | 68 ° | 68 ° | 68 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 440 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1105 mm | 1131 mm | 1157 mm | 1182 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm | 60 mm |
| Standover Height | 777 mm | 803 mm | 831 mm | 860 mm |
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Ice Cream Truck completes the Surly Ice model. Surly released 12 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Fatbike bikes average price
If you want to purchase a solid Fatbike bike, it is important to know that the average cost is 1743$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Surly Ice Cream Truck price was 2099$. Doing a quick comparison, we notice that Ice Cream Truck price is 20.42% more expensive than the average cost of a Fatbike bike.
Ice Cream Truck components
Fork material
Ice Cream Truck has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The Ice Cream Truck 2020 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Surly Ice Cream Truck has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
This bike is available in 4 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
