Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 650b / 29" -
Groupset Deore, NX -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
SM
158cm - 171cm
MD
168cm - 180cm
MD
168cm - 180cm
LG
178cm - 189cm
LG
178cm - 189cm
XL
186cm - 199cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Ogre, Surly 4130 CroMoly steel. Surly Ogre, Surly 4130 CroMoly steel. Main triangle double-butted. TIG-welded
Suspension Fork
Surly Ogre, TIG-welded 4130 CroMoly, non-suspension corrected, tapered and butted straight blade. Surly Ogre, TIG-welded 4130 CroMoly, non-suspension corrected, tapered and butted straight blade. Low- and mid-blade fully threaded through-blade rack eyelets; fender mount eyelets at dropout; 1-1/8? x 285mm threadless steer tube, 51mm disc mount (203mm max. rotor diameter), line/housing guides; two sets of bottle cage mounts, each height adjustable (note: cages cannot be used on fork with some racks, and vice versa)
Drivetrain
Rear Derailleur
Shimano Deore RD-M6000
Front Derailleur
N/A
Shift Levers
Shimano Deore M6000
Cassette
Microshift 10 spd, 11-42t
Crank
SRAM NX 32T
Bottom Bracket
SRAM Powerspline
Chain
KMC x10
Wheels
Front Hub
Novatec 32h QR
Rear Hub
Novatec 32h, Thru axle
Rims
WTB i29 Black
Tires
Surly Extra Terrestrial 29x2.5” 60TPI Slate-wall Tubeless Ready
Brakes
Brakes
Tektro HD-M275
Brake Levers
Tektro HD-M275
Disk Rotors
Tektro 160/160mm
Cockpit
Stem
ProMax 31.8, 4 bolt
Handlebar
Salsa Bend
Headset
Cane Creek 40
Seat
Saddle
WTB Volt Sport
Seatpost
ProMax 27.2, 300L, offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | MD | MD | LG | LG | XL | XL |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.49 mm | 1.46 mm | 1.46 mm | 1.43 mm | 1.43 mm | 1.41 mm | 1.41 mm |
| Front Center | 618 mm | 618 mm | 633 mm | 633 mm | 653 mm | 653 mm | 679 mm | 679 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62 mm | 68 mm | 58 mm | 64 mm | 58 mm | 64 mm | 58 mm | 64 mm |
| Stack | 598.4 mm | 598.4 mm | 609.8 mm | 609.8 mm | 619.4 mm | 619.4 mm | 638.4 mm | 638.4 mm |
| Reach | 401.9 mm | 401.9 mm | 416.9 mm | 416.9 mm | 434 mm | 434 mm | 453.4 mm | 453.4 mm |
| Top Tube Length | 581.4 mm | 581.4 mm | 601.4 mm | 601.4 mm | 621.4 mm | 621.4 mm | 646.4 mm | 646.4 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406.4 mm | 406.4 mm | 457.2 mm | 457.2 mm | 508 mm | 508 mm | 558 mm | 558 mm |
| Head Tube Angle | 71.5 ° | 71.5 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 110 mm | 120 mm | 120 mm | 130 mm | 130 mm | 150 mm | 150 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1055 mm | 1055 mm | 1070 mm | 1070 mm | 1091 mm | 1091 mm | 1116 mm | 1116 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 769 mm | 769 mm | 802 mm | 802 mm | 830 mm | 830 mm | 864 mm | 864 mm |
| Wheels | 650 | 29" | 650 | 29" | 650 | 29" | 650 | 29" |
| Rider Min Height | 158 cm | 158 cm | 168 cm | 168 cm | 178 cm | 178 cm | 186 cm | 186 cm |
| Rider Max Height | 171 cm | 171 cm | 180 cm | 180 cm | 189 cm | 189 cm | 199 cm | 199 cm |
Model Overview
Ogre belongs to the Surly Ogre model. Surly launched 12 bikes of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Touring bikes
According to our calculations, the average cost of a Touring bike that is reliable is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
When Surly released this model in 2020, its price was 1525$. If we compare this with the average Touring bike cost we notice that the price is 51.44% higher.
Ogre components
Fork material
The fork is made out of steel, which is tougher than carbon in the case of an impact. However, it can add some extra weight to the bike.
Wheels
The Ogre 2020 bike is equipped with aluminum wheels when leaving the factory. 650b wheels make a great choice if you want to sacrifice speed for comfort. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Surly Ogre is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
Surly Ogre bike has 8 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
