Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 29" -
Groupset microSHIFT Advent X, NX -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Suspension Fork
100% Surly Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
Drivetrain
Rear Derailleur
Microshift RD-M6205 with Clutch
Front Derailleur
N/A
Shift Levers
Microshift SL-M9605 Trail Pro
Crank
SRAM NX 32t
Bottom Bracket
SRAM Powerspline
Chain
KMC X10
Wheels
Front Hub
Novatec 9x100 QR, 6-bolt disc
Rear Hub
Novatec 12x142 QR, 6-bolt disc
Rims
WTB i29
Tires
Surly ExtraTerrestrial 29x2.5" 60tpi, Tubeless Ready
Brakes
Brakes
Avid BB5
Brake Levers
Tektro FR5
Cockpit
Stem
Kalloy 31.8
Handlebar
Salsa Bend
Headset
Cane Creek
Seat
Saddle
WTB Volt
Seatpost
ProMax 27.2x300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.46 mm | 1.43 mm | 1.41 mm |
| Front Center | 618 mm | 633 mm | 653 mm | 679 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 72 mm | 68 mm | 68 mm | 68 mm |
| Stack | 598.4 mm | 609.8 mm | 619.4 mm | 638.4 mm |
| Reach | 401.9 mm | 416.9 mm | 434 mm | 453.4 mm |
| Top Tube Length | 581.4 mm | 601.4 mm | 621.4 mm | 646.4 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406.4 mm | 457.2 mm | 508 mm | 558 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1055 mm | 1070 mm | 1091 mm | 1116 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 769 mm | 802 mm | 830 mm | 864 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
About this model
Ogre completes the Surly Ogre model. Surly released 12 bikes variations of this model so far. You can easily view all of the Surly Ogre bikes models from 2022, here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Gravel bikes
Our math shows that the average cost of a dependable Gravel bike is 2462$. However, even though the average price of a Gravel bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1749$. In conclusion, this bike price is 40.77% smaller than the price of the average Gravel bike.
Ogre components
Fork material
Ogre has a steel fork, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
When it comes to wheels, the Ogre bike is equipped with the 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the bike itself.
Brakes
Nothing is more important on a bike than its ability to brake properly. Surly Ogre is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Surly Ogre bike has 4 sizes, in the range of 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
