Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Steel -
Wheels 29" -
Groupset microSHIFT Advent X, NX -
Suspension Rigid -
Drivetrain 1 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Suspension Fork
100% Surly Chromoly Steel, Natch tubing, double-butted tapered fork blades, TIG welded, E.D. coated
Drivetrain
Rear Derailleur
Microshift RD-M6205 with Clutch
Front Derailleur
N/A
Shift Levers
Microshift SL-M9605 Trail Pro
Crank
SRAM NX 32t
Bottom Bracket
SRAM Powerspline
Chain
KMC X10
Wheels
Front Hub
Novatec 9x100 QR, 6-bolt disc
Rear Hub
Novatec 12x142 QR, 6-bolt disc
Tires
Surly ExtraTerrestrial 29x2.5" 60tpi, Tubeless Ready
Brakes
Brakes
Avid BB5
Brake Levers
Tektro FR5
Cockpit
Stem
Kalloy 31.8
Handlebar
Salsa Bend
Headset
Cane Creek
Seat
Saddle
WTB Volt
Seatpost
ProMax 27.2x300
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.46 mm | 1.43 mm | 1.41 mm |
| Front Center | 618 mm | 633 mm | 653 mm | 679 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 72 mm | 68 mm | 68 mm | 68 mm |
| Stack | 598.4 mm | 609.8 mm | 619.4 mm | 638.4 mm |
| Reach | 401.9 mm | 416.9 mm | 434 mm | 453.4 mm |
| Top Tube Length | 581.4 mm | 601.4 mm | 621.4 mm | 646.4 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 406.4 mm | 457.2 mm | 508 mm | 558 mm |
| Head Tube Angle | 71.5 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 120 mm | 130 mm | 150 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1055 mm | 1070 mm | 1091 mm | 1116 mm |
| Bottom Bracket Drop | 68 mm | 68 mm | 68 mm | 68 mm |
| Standover Height | 769 mm | 802 mm | 830 mm | 864 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Ogre Frameset is a Surly Ogre model. 12 frames variations carry this model name so far. Check out the entire range from 2022 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Gravel frames average price
Our math shows that the average cost of a dependable Gravel frame is 1505$. However, even though the average price of a Gravel frame is lower, you might still be able to get a top-quality frame. To make sure you don’t pay a higher amount than normal for your frame, always do some components analysis and read reviews.
When Surly released this model in 2022, its price was 949$. Comparing this to the average Gravel frame price, we see that the price is 58.59% lower.
Ogre Frameset components
Fork material
When it comes to the fork, this frame has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Brakes
When you want to stop the bike in time, the brakes are vital. The Ogre Frameset has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Ogre Frameset comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, it won’t take much to find one that’s right for you.
