Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" / 650b -
Groupset Tiagra, Shimano -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Pack Rat, Surly 4130 CroMoly steel. Surly Pack Rat, Surly 4130 CroMoly steel. Main triangle double-butted. TIG-welded. ED coated
Suspension Fork
Surly Pack Rat, 4130 CroMoly, lugged & brazed. Surly Pack Rat, 4130 CroMoly, lugged & brazed. Sloping crown w/threaded eyelets, tapered & butted curved blades w/mid-blade rack eyelets, dual dropout eyelets
Drivetrain
Rear Derailleur
Shimano Tiagra RD-4700 GS
Front Derailleur
Shimano Tiagra FD-4700
Shift Levers
Shimano Tiagra ST-4700
Cassette
Microshift 10 spd, 11-34t
Crank
Shimano FC-R460 48x34t
Bottom Bracket
Shimano BB-RS500
Chain
KMC X10
Wheels
Front Hub
Formula RB-51 32h QR
Rear Hub
Formula RB-52 32h QR
Rims
Alex Adventurer 2, Tubeless Ready
Tires
26/650b- Panaracer Pasela 26x1.5, 650b x 42
Brakes
Brakes
Tektro CR720
Brake Levers
Shimano Tiagra ST-4700
Cockpit
Stem
ProMax 31.8 4 bolt
Handlebar
ProMax Flare-Out
Headset
Cane Creek custom 5, 1-1/8"
Seat
Saddle
WTB Volt Sport
Seatpost
ProMax 27.2 350L offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 38cm | 42cm | 46cm | 50cm | 52cm | 54cm | 56cm | 58cm |
|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.21 mm | 1.24 mm | 1.26 mm | 1.27 mm | 1.31 mm | 1.33 mm | 1.34 mm | 1.34 mm |
| Front Center | 554 mm | 557 mm | 559 mm | 569 mm | 577 mm | 587 mm | 597 mm | 606 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 50 mm | 54 mm | 62 mm | 64 mm | 46 mm | 45 mm | 45 mm | 50 mm |
| Stack | 452 mm | 468 mm | 481 mm | 495 mm | 515 mm | 529 mm | 544 mm | 558 mm |
| Reach | 374 mm | 376 mm | 383 mm | 389 mm | 394 mm | 399 mm | 405 mm | 415 mm |
| Top Tube Length | 492 mm | 502 mm | 517 mm | 532 mm | 547 mm | 562 mm | 577 mm | 592 mm |
| Seat Tube Angle | 75.5 ° | 75.5 ° | 75.5 ° | 75.5 ° | 73.5 ° | 73 ° | 72.5 ° | 72 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Angle | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Head Tube Length | 90 mm | 105 mm | 120 mm | 135 mm | 130 mm | 145 mm | 160 mm | 175 mm |
| Chainstay Length | 407 mm | 407 mm | 407 mm | 407 mm | 412 mm | 412 mm | 412 mm | 412 mm |
| Wheelbase | 957 mm | 960 mm | 962 mm | 972 mm | 983 mm | 993 mm | 1003 mm | 1012 mm |
| Bottom Bracket Drop | 45 mm | 45 mm | 45 mm | 45 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 682 mm | 708 mm | 733 mm | 759 mm | 788 mm | 804 mm | 820 mm | 836 mm |
| Wheels | 26" | 26" | 26" | 26" | 650 | 650 | 650 | 650 |
Model Overview
Pack Rat belongs to the Surly Pack model. There are 6 bikes that carry this model name. Check out the entire range from 2019 of this model, by clicking this link.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Touring bikes
According to our math, the average price for a trustworthy Touring bike is 1007$. However, even though the average price of a Touring bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Surly released this model in 2019, its price was 1475$. In conclusion, this bike price is 46.47% more expensive than the price of the average Touring bike.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels
The wheels on Pack Rat are the 26″ aluminum type. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Surly Pack Rat is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
