Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Groupset SLX, Race Face -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Pugsley, 100% Surly NATCH 4130 Chromoly steel. Double-butted main triangle. TIG-welded. Offset laced wheels. 142mm, 135mm with 10/12 adaptors.
Suspension Fork
Surly Pugsley, Tapered straight blade NATCH 4130 Chromoly. Offset laced wheels. 135mm spacing.
Drivetrain
Rear Derailleur
Shimano SLX RD-7000 GS 11 Speed
Front Derailleur
None
Shift Levers
Shimano SLX-11
Cassette
Sunrace 11 speed, 11-46
Crank
Race Face AEffect, 30T
Bottom Bracket
Race Face
Chain
KMC X11-1 EPT Anti-Rust
Wheels
Front Hub
Surly Ultra New, Freewheel, Bolt-on
Rear Hub
Shimano FH-M525, 32h QR
Rims
Surly My Other Brother Darryl (80mm), black, dual hole pattern, Tubeless Ready
Tires
Surly Edna, 26x4.3, 60 TPI, Tubeless Ready
Brakes
Brakes
Avid BB7 Mountain
Brake Levers
SRAM FR-5
Disk Rotors
SRAM Centerline 160/160mm
Cockpit
Stem
ProMax 31.8
Handlebar
Surly Moloko Bar
Headset
Cane Creek
Seat
Saddle
WTB Volt Sport
Seatpost
2 Bolt 27.2
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.49 mm | 1.51 mm | 1.49 mm | 1.47 mm | 1.45 mm |
| Bottom Bracket Height | 278 mm | 278 mm | 278 mm | 278 mm | 278 mm |
| Front Center | 624 mm | 634 mm | 654 mm | 675 mm | 695 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 82 mm | 83 mm | 82 mm | 82 mm | 82 mm |
| Stack | 567 mm | 581 mm | 594.5 mm | 609.5 mm | 623.5 mm |
| Reach | 379.5 mm | 384.5 mm | 399.5 mm | 414.5 mm | 430.5 mm |
| Top Tube Length | 554.5 mm | 574.5 mm | 594.5 mm | 614.5 mm | 634.5 mm |
| Seat Tube Angle | 73 ° | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 326.5 mm | 376.5 mm | 427 mm | 478 mm | 529 mm |
| Head Tube Angle | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 100 mm | 115 mm | 130 mm | 145 mm | 160 mm |
| Chainstay Length | 454 mm | 454 mm | 454 mm | 454 mm | 454 mm |
| Wheelbase | 1070 mm | 1080 mm | 1100 mm | 1121 mm | 1142 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm | 65 mm | 65 mm |
| Standover Height | 728 mm | 756 mm | 788 mm | 820 mm | 851 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Pugsley belongs to the Surly Pugsley model. Surly released 7 bikes variations of this model so far. Check out the entire range from 2020 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Fatbike bikes average price
If you want an acceptable Fatbike bike you should know that the average price is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Surly Pugsley price was 1900$. Comparing this to the average Fatbike bike price, we see that the price is 9.01% more expensive.
Overview of components
Fork material
When it comes to the fork, this bike has a steel one, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels size
The Pugsley 2020 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Surly Pugsley is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, performance-wise there is room for improvement.
Sizes
Surly Pugsley bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
