Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 700c -
Suspension Rigid -
Drivetrain Single Speed -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Steamroller 100% 4130 CroMoly steel. Double-butted main triangle . TIG-welded. ED Coated
Suspension Fork
4130 CroMoly, lugged and brazed flat crown that is drilled to accept a standard mid-reach (47–57mm) caliper brake. It has clearance for 700c x 38mm tires. There are no eyelets at the dropouts
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
Lida, 18T 3/32"
Crank
Samox AF19-D45S, 45T
Bottom Bracket
68mm wide, threaded English 1.37? x 24t
Chain
KMC Z610H
Wheels
Front Hub
Surly Ultra New 32H, 100mm Black with bolts
Rear Hub
Surly Ultra New 32H, Fix/Free, 120mm, Black with bolts
Rims
Alex Adventurer 2
Tires
Continental Contact 700cx32mm
Brakes
Brakes
Tektro R559 road caliper
Brake Levers
Tektro CL-520-RS, black
Cockpit
Stem
HL 25.4
Handlebar
Dimension Arc
Headset
Cane Creek custom 5 series
Seat
Saddle
WTB Volt Sport
Seatpost
Kalloy SP-368 non-offset, 27.2x300mm, black
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 53cm | 56cm | 59cm | 62cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.3 mm | 1.34 mm | 1.38 mm | 1.43 mm | 1.46 mm |
| Front Center | 578 mm | 579 mm | 591 mm | 600 mm | 621 mm |
| Rake | 38 mm | 38 mm | 38 mm | 38 mm | 38 mm |
| Trail | 62 mm | 67 mm | 64 mm | 61 mm | 61 mm |
| Stack | 509.9 mm | 536.3 mm | 563.8 mm | 591.4 mm | 623.1 mm |
| Reach | 393.1 mm | 399 mm | 407.3 mm | 413.2 mm | 425.6 mm |
| Top Tube Length | 534.5 mm | 552 mm | 573 mm | 592 mm | 613 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 490 mm | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 72.5 ° | 73 ° | 73.5 ° | 74 ° | 74 ° |
| Head Tube Length | 83 mm | 109 mm | 136 mm | 163 mm | 196 mm |
| Chainstay Length | 403 mm | 403 mm | 403 mm | 403 mm | 403 mm |
| Wheelbase | 970 mm | 971 mm | 983 mm | 993 mm | 1014 mm |
| Bottom Bracket Drop | 70 mm | 70 mm | 70 mm | 70 mm | 70 mm |
| Standover Height | 753 mm | 785 mm | 812 mm | 840 mm | 870 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
Model Overview
Steamroller completes the Surly Steamroller model. 8 bikes variations carry this model name so far. You can get a glimpse at all models from 2017, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Hipster bikes
If you want to purchase a solid Hipster bike, it is important to know that the average cost is 612$. However, this doesn’t mean that if you spend less money on a Hipster bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Steamroller components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The wheels on Steamroller are the 700c aluminum type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Surly Steamroller has Rim brakes installed. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
