Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Groupset SX Eagle, NX Eagle -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Surly Wednesday, 100% Surly 4130 Chromoly steel. 100% Surly Chromoly Steel, Natch tubing, double-butted main triangle, TIG welded, E.D. coated
Suspension Fork
Surly Wednesday, Tapered straight blade 4130 Chromoly. Surly Wednesday, Tapered straight blade 4130 Chromoly. 468mm axle to crown, 47mm offset. 51mm I.S. front standard disc mount, 150mm x 15mm thru-axle dropouts (axle included), 100mm suspension fork compatible
Drivetrain
Rear Derailleur
SRAM SX Eagle
Front Derailleur
n/a
Shift Levers
SRAM SX Eagle 12-spd
Cassette
SRAM Eagle 11-50t
Crank
SRAM NX Eagle DUB
Bottom Bracket
SRAM DUB
Chain
SRAM SX Eagle 12-spd
Wheels
Front Hub
Novatec 15 x 150mm, 32h, 6-bolt
Rear Hub
Novatec 12 x 177mm, 32h, 6-bolt
Rims
Surly My Other Brother Darryl
Tires
Surly Nate 26 x 3.8?, 60tpi, tubeless ready
Brakes
Brakes
SRAM Avid BB5 Mechanical, 160mm rotors front & rear
Brake Levers
SRAM Avid FR-5
Cockpit
Stem
Kalloy 31.8
Handlebar
OE 31.8mm
Headset
Cane Creek
Seat
Saddle
WTB Volt
Seatpost
Kalloy 30.9
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.38 mm | 1.35 mm | 1.32 mm | 1.29 mm |
| Bottom Bracket Height | 288 mm | 288 mm | 288 mm | 288 mm | 288 mm |
| Front Center | 652 mm | 672 mm | 693 mm | 714 mm | 735 mm |
| Rake | 47 mm | 47 mm | 47 mm | 47 mm | 47 mm |
| Trail | 81 mm | 83 mm | 81 mm | 81 mm | 81 mm |
| Stack | 574 mm | 579 mm | 588 mm | 598 mm | 607 mm |
| Reach | 401 mm | 421 mm | 437 mm | 454 mm | 472 mm |
| Top Tube Length | 571 mm | 591 mm | 611 mm | 631 mm | 651 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 316 mm | 366 mm | 416 mm | 466 mm | 516 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 95 mm | 100 mm | 110 mm | 120 mm | 130 mm |
| Chainstay Length | 436 mm | 436 mm | 436 mm | 436 mm | 436 mm |
| Wheelbase | 1082 mm | 1102 mm | 1123 mm | 1144 mm | 1165 mm |
| Bottom Bracket Drop | 55 mm | 55 mm | 55 mm | 55 mm | 55 mm |
| Standover Height | 712 mm | 738 mm | 775 mm | 808 mm | 842 mm |
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Wednesday completes the Surly Wednesday model. 12 bikes variations carry this model name so far. Take a sneak peek at all Surly Wednesday bikes models from 2023, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Fatbike bikes
If you want to purchase a solid Fatbike bike, it is important to know that the average cost is 1743$. However, even though the average price of a Fatbike bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Surly released this model in 2023, its price was 1849$. Doing a quick comparison, we notice that Wednesday price is 6.08% higher than the average cost of a Fatbike bike.
Overview of components
Fork material
The fork is made out of steel, so, it can add some extra weight to your bike. However, steel is a pretty tough and durable material.
Wheels size
The Wednesday 2023 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
Wednesday comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
