Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Groupset Altus -
Suspension Rigid -
Motor Bosch 250W 50Nm mid-drive -
Battery Bosch PowerPack 400 -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tern Quick Haul, Patented Design, 6061-AL, EFBE Tri-Test approved: 150 kg
Suspension Fork
Cargo, steel, EFBE approved: 150 kg
Drivetrain
Rear Derailleur
Shimano Altus Shadow
Shift Levers
Shimano Altus, 1 x 9 spd, trigger
Cassette
Shimano 11-34T, 9 spd
Crank
Tern custom, forged 6061-AL crankarm
Bottom Bracket
Motor integrated
Chain
KMC for eBike, 9 spd
Chain Guide
SKS Chainblade
Pedals
Contec CP-030
Wheels
Front Hub
Disc, aluminum
Rear Hub
9 spd, disc, aluminum
Rims
Schürmann, Disc
Tires
Schwalbe Big Apple, 55-406, puncture protection, Reflex
Brakes
Brakes
Hydraulic Disc
Brake Levers
Clarks, hydraulic disc
Cockpit
Stem
Speedlifter, 150 mm extension, 3D Forged stem, 31.8
Handlebar
Low riser, 31.8, 6061-AL
Headset
Tern Flux by FSA, cartridge bearings, Physis integrated
Seat
Saddle
Velo Comfort
Seatpost
31.6 mm, 6061-AL, micro-adjust clamp
Motor & Battery
Motor
Bosch Active Line Plus, 270% Assist, 50 Nm Torque, max speed 25 kph (EU)
Battery
Bosch PowerPack 400
Model Overview
Quick Haul D9 belongs to the Tern E Quick model. Tern launched 14 e-bikes of this model so far. You can easily view all of the Tern E Quick e-bikes models from 2022, here.
Model range prices
Tern Quick Haul D8 2022 is the most economical model, with a starting price of 2999$. Tern Quick Haul P5i 2022 on the other hand costs 3821$, and is the most expensive model.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Utility e-bikes average price
According to our math, the average price for a trustworthy Utility e-bike is 3636$. However, even though the average price of an Utility e-bike is lower, you might still be able to get a top-quality e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
At the moment of the release date, Tern Quick Haul D9 price was 3290$. Comparing this to the average Utility e-bike price, we see that the price is 10.52% lower.
Quick Haul D9 components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
When leaving the production line, the Quick Haul D9 model has 20″ aluminum wheels. The 20″ wheels are a good fit for folding bikes, BMX, or children bikes. In conclusion, you can use them better on-road, and less on technical terrain.
Brakes
For your safety, it is important to have quality breaks on your bike. Tern Quick Haul D9 has Hydraulic Disc brakes installed. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
Tern Quick Haul D9 2022 is available in one size only. In conclusion, double-check its size to make sure it’s a good fit for you.
