Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Force eTAP, SRAM -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Thesis OB1 Carbon
Suspension Fork
Thesis OB1 Carbon with SteerSafe
Drivetrain
Rear Derailleur
SRAM Force AXS 12spd Electronic
Front Derailleur
SRAM Force eTap AXS Electronic
Shift Levers
SRAM Force AXS HRD Electronic/Hydraulic
Cassette
SRAM Force XG-1270 10-33T 12spd
Crank
SRAM 46/33T
Bottom Bracket
Thesis 2-Piece Aluminum Interlocking
Chain
SRAM Force AXS
Wheels
Front Hub
DT Swiss DT350
Rear Hub
DT Swiss DT350
Rims
THESIS U/V Aero-Wide Carbon 700C
Spokes
Pillar PSR X-TRA 1420 Cold-Forged Bladed
Tires
WTB Exposure 30 Road
Brakes
Brakes
SRAM Force AXS HRD Electronic/Hydraulic
Disk Rotors
SRAM Centerline XR Centerlock 160mm
Cockpit
Stem
Thesis Ultralight
Handlebar
Thesis Compact Ergo Flare
Headset
Thesis Oversized Integrated
Seat
Saddle
Thesis Endurance 148 Saddle
Seatpost
Thesis Ultralight 3D Forged ? 1-piece 3D forged 2014-T6 aluminum quill ? Micro-adjustable 2-bolt clamp ? Broadly supportive lower clamp ? 0 offset to match OB1's 73° seattube angle ? 230g
Motor & Battery
Charger
SRAM AXS Powerpack Dual Battery Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.51 mm | 1.5 mm | 1.53 mm | 1.52 mm |
| Bottom Bracket Height | 276 mm | 276 mm | 276 mm | 276 mm | 276 mm |
| Front Center | 578 mm | 586 mm | 598 mm | 616 mm | 637 mm |
| Rake | 51 mm | 51 mm | 51 mm | 51 mm | 51 mm |
| Trail | 73 mm | 66 mm | 60 mm | 60 mm | 60 mm |
| Stack | 527 mm | 557 mm | 577 mm | 601 mm | 620 mm |
| Reach | 362 mm | 369 mm | 384 mm | 394 mm | 409 mm |
| Top Tube Length | 521 mm | 537 mm | 553 mm | 576 mm | 597 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 440 mm | 470 mm | 500 mm | 530 mm | 560 mm |
| Head Tube Angle | 70 ° | 71 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 110 mm | 138 mm | 155 mm | 180 mm | 200 mm |
| Chainstay Length | 426 mm | 426 mm | 426 mm | 426 mm | 426 mm |
| Wheelbase | 993 mm | 1001 mm | 1013 mm | 1031 mm | 1052 mm |
| Bottom Bracket Drop | 73 mm | 73 mm | 73 mm | 73 mm | 73 mm |
| Standover Height | 726 mm | 756 mm | 781 mm | 811 mm | 841 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
The OB1 AXS 2x — 700 completes the Thesis Ob1 model. Thesis released 6 bikes variations of this model so far. You can get a glimpse at all models from 2020, by clicking on this link.
Model range prices
Thesis The OB1 — 650b 2020 is the cheapest bike model and costs 3299$. Thesis The OB1 AXS 2x — 700 2020 is the most expensive one and costs 5199$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Gravel bikes average price
If you want to purchase a solid Gravel bike, it is important to know that the average cost is 2462$. However, this doesn’t mean that if you spend less money on a Gravel bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5199$. If we compare this with the average Gravel bike cost we notice that the price is 111.17% more expensive.
The OB1 AXS 2x — 700 components
Fork material
The fork is made out of carbon, so, it is super light and stiff. In conclusion, a carbon fork gives you great control when steering, and is also more forgiving.
Wheels size
When it comes to wheels, the The OB1 AXS 2x — 700 bike is equipped with the 700c carbon model. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Thesis The OB1 AXS 2x — 700 has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
The OB1 AXS 2x — 700 comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
