Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Groupset Deore -
Suspension Full -
Motor Shimano 250W 85Nm mid-drive -
Battery Battery E2 726Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
SM
158cm - 170cm
SM
158cm - 170cm
MD
168cm - 182cm
MD
168cm - 182cm
MD
168cm - 182cm
LG
178cm - 192cm
LG
178cm - 192cm
LG
178cm - 192cm
XL
186cm - 199cm
XL
186cm - 199cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Marzzochi Bomber Z2 150mm 29"
Rear Shock
Fox Float-A DPS 140mm shock
Drivetrain
Rear Derailleur
Deore, 11-speed, 34, 11/51
Cassette
Deore Compact 11/51T
Crank
Deore 34T
Pedals
Well go normal
Wheels
Rims
DT Swiss H1900 29" 30mm
Tires
Schwalbe Smart Sam 29x2.60
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Stem Thömus TIC, 60 mm
Handlebar
Handlebar Thömus Alu Riser 15mm, 780mm
Seat
Saddle
Selle Italia X-Base, black
Seatpost
Seat post Thömus aluminum
Motor & Battery
Motor
Motor Shimano EP6
Battery
Battery E2 726Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | SM | MD | MD | MD | LG | LG | LG | XL | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.436 mm | 1.482 mm | 1.51 mm | 1.361 mm | 1.402 mm | 1.424 mm | 1.295 mm | 1.335 mm | 1.355 mm | 1.24 mm | 1.276 mm | 1.295 mm |
| Bottom Bracket Height | 346 mm | 353 mm | 355 mm | 346 mm | 351 mm | 355 mm | 346 mm | 353 mm | 355 mm | 346 mm | 353 mm | 355 mm |
| Stack | 609 mm | 615 mm | 619 mm | 618 mm | 624 mm | 628 mm | 627 mm | 634 mm | 637 mm | 631 mm | 638 mm | 641 mm |
| Reach | 424 mm | 415 mm | 410 mm | 454 mm | 445 mm | 441 mm | 484 mm | 475 mm | 470 mm | 509 mm | 500 mm | 495 mm |
| Top Tube Length | 572 mm | 575 mm | 576 mm | 609 mm | 612 mm | 613 mm | 645 mm | 648 mm | 649 mm | 674 mm | 677 mm | 678 mm |
| Seat Tube Angle | 76.3 ° | 75.4 ° | 75 ° | 75.9 ° | 75 ° | 74.6 ° | 75.6 ° | 74.7 ° | 74.3 ° | 75.4 ° | 74.5 ° | 74.1 ° |
| Seat Tube Length | 400 mm | 400 mm | 400 mm | 440 mm | 440 mm | 440 mm | 480 mm | 480 mm | 480 mm | 500 mm | 500 mm | 500 mm |
| Head Tube Angle | 66.4 ° | 65.5 ° | 65.1 ° | 66.4 ° | 65.5 ° | 65.1 ° | 66.4 ° | 65.5 ° | 65.1 ° | 66.4 ° | 65.5 ° | 65.1 ° |
| Chainstay Length | 455 mm | 453 mm | 455 mm | 455 mm | 453 mm | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Bottom Bracket Drop | 28 mm | 21 mm | 19 mm | 28 mm | 23 mm | 19 mm | 28 mm | 21 mm | 19 mm | 28 mm | 21 mm | 19 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 158 cm | 158 cm | 168 cm | 168 cm | 168 cm | 178 cm | 178 cm | 178 cm | 186 cm | 186 cm | 186 cm |
| Rider Max Height | 170 cm | 170 cm | 170 cm | 182 cm | 182 cm | 182 cm | 192 cm | 192 cm | 192 cm | 199 cm | 199 cm | 199 cm |
Model Overview
Lightrider E2 Pro Deore Schwarz is part of the Thoemus E Lightrider model. There are 14 e-bikes that carry this model name. Take a sneak peek at all Thoemus E Lightrider e-bikes models from 2023, by clicking here.
Model range prices
Thoemus Lightrider E2 Deore Aare 2023 is the most affordable e-bike of this model and has a price of 8146$. On the other hand, Thoemus Lightrider E2 XT Rot 2023, is the most expensive and costs 9887$.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail e-bikes average price
If you want to purchase a solid Trail e-bike, it is important to know that the average cost is 3365$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail e-bike. As a general rule of thumb, you should always read reviews about the e-bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Rear Shock
From the factory, it comes with the Fox Float-A DPS 140mm shock rear shock model, which has a travel of 140mm. Bike rear shocks increase the riding comfort, and also give you more control over technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
When it comes to wheels, the Lightrider E2 Pro Deore Schwarz e-bike is equipped with the 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Thoemus Lightrider E2 Pro Deore Schwarz has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 12 sizes. They vary from 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, you won’t have a problem finding one that suits you.
