Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 150mm -
Travel Rear 140mm -
Groupset SLX -
Suspension Full -
Motor Shimano hub-drive -
Battery Battery E2 726Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
SM
158cm - 170cm
SM
158cm - 170cm
MD
168cm - 182cm
MD
168cm - 182cm
MD
168cm - 182cm
LG
178cm - 192cm
LG
178cm - 192cm
LG
178cm - 192cm
XL
186cm - 199cm
XL
186cm - 199cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Marzzochi Bomber Z2 150mm 29"
Rear Shock
Fox Float-A DPS 140mm shock
Drivetrain
Rear Derailleur
SLX, 12-speed, 34, 10-51, incl. 4-piston brake
Cassette
EP8 SLX Compact 10-51T
Crank
SLX 34T
Pedals
Acros A Flat MTB
Wheels
Rims
DT Swiss H1900 29" 30mm
Tires
Schwalbe Smart Sam 29x2.60
Brakes
Brakes
Hydraulic Disc
Cockpit
Stem
Stem Thömus TIC, 60 mm
Handlebar
Handlebar Thömus Alu Riser 15mm, 780mm
Seat
Saddle
Selle Italia X-Base, black
Seatpost
Seat post Thömus aluminum
Motor & Battery
Motor
Motor Shimano EP801
Battery
Battery E2 726Wh
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | SM | SM | MD | MD | MD | LG | LG | LG | XL | XL | XL |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.436 mm | 1.482 mm | 1.51 mm | 1.361 mm | 1.402 mm | 1.424 mm | 1.295 mm | 1.335 mm | 1.355 mm | 1.24 mm | 1.276 mm | 1.295 mm |
| Bottom Bracket Height | 346 mm | 353 mm | 355 mm | 346 mm | 351 mm | 355 mm | 346 mm | 353 mm | 355 mm | 346 mm | 353 mm | 355 mm |
| Stack | 609 mm | 615 mm | 619 mm | 618 mm | 624 mm | 628 mm | 627 mm | 634 mm | 637 mm | 631 mm | 638 mm | 641 mm |
| Reach | 424 mm | 415 mm | 410 mm | 454 mm | 445 mm | 441 mm | 484 mm | 475 mm | 470 mm | 509 mm | 500 mm | 495 mm |
| Top Tube Length | 572 mm | 575 mm | 576 mm | 609 mm | 612 mm | 613 mm | 645 mm | 648 mm | 649 mm | 674 mm | 677 mm | 678 mm |
| Seat Tube Angle | 76.3 ° | 75.4 ° | 75 ° | 75.9 ° | 75 ° | 74.6 ° | 75.6 ° | 74.7 ° | 74.3 ° | 75.4 ° | 74.5 ° | 74.1 ° |
| Seat Tube Length | 400 mm | 400 mm | 400 mm | 440 mm | 440 mm | 440 mm | 480 mm | 480 mm | 480 mm | 500 mm | 500 mm | 500 mm |
| Head Tube Angle | 66.4 ° | 65.5 ° | 65.1 ° | 66.4 ° | 65.5 ° | 65.1 ° | 66.4 ° | 65.5 ° | 65.1 ° | 66.4 ° | 65.5 ° | 65.1 ° |
| Chainstay Length | 455 mm | 453 mm | 455 mm | 455 mm | 453 mm | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm | 455 mm |
| Bottom Bracket Drop | 28 mm | 21 mm | 19 mm | 28 mm | 23 mm | 19 mm | 28 mm | 21 mm | 19 mm | 28 mm | 21 mm | 19 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 158 cm | 158 cm | 168 cm | 168 cm | 168 cm | 178 cm | 178 cm | 178 cm | 186 cm | 186 cm | 186 cm |
| Rider Max Height | 170 cm | 170 cm | 170 cm | 182 cm | 182 cm | 182 cm | 192 cm | 192 cm | 192 cm | 199 cm | 199 cm | 199 cm |
Model Overview
Lightrider E2 Pro EP8 SLX Weiss is a Thoemus E Lightrider model. There are 14 e-bikes that carry this model name. Take a sneak peek at all Thoemus E Lightrider e-bikes models from 2023, by clicking here.
Model range prices
Thoemus Lightrider E2 Deore Aare 2023 is the cheapest e-bike model and costs 8146$. Thoemus Lightrider E2 XT Rot 2023 is the most expensive one and costs 9887$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Trail e-bikes
If you want an acceptable Trail e-bike you should know that the average price is 3365$. However, this doesn’t mean that if you spend less money on a Trail e-bike, you couldn’t get a decent one. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Overview of components
Rear Shock
The Lightrider E2 Pro EP8 SLX Weiss has a rear shock with a travel of 140mm. The model Fox Float-A DPS 140mm shock is the one installed in this e-bike. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on Lightrider E2 Pro EP8 SLX Weiss are the 29″ aluminum type. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
For your safety, it is important to have quality breaks on your bike. Thoemus Lightrider E2 Pro EP8 SLX Weiss has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
There are 12 sizes available for this model. Rider height can be anywhere between 158 cm – 199 cm (5.18 ft – 6.53 ft). In conclusion, finding one for you shouldn’t be a problem.
