Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame aluminium -
Wheels 700c -
Groupset Tiagra -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Mechanical Disc
Sizing
Recommended size guide.
XS
157cm - 169cm
SM
166cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Tommaso 6061 SLA Aluminum Compact Road Frame
Suspension Fork
Tommaso HCT Carbon Fiber Fork with 1 1/8€ Aluminum Steer Tube
Drivetrain
Rear Derailleur
Shimano Tiagra 4700 (10-spd)
Front Derailleur
Shimano Tiagra 4700 (2-spd)
Shift Levers
Shimano Tiagra
Cassette
Shimano Tiagra 4700 - 11-32t - (10spd)
Crank
Shimano Tiagra 50/34t Compact
Bottom Bracket
Shimano Tiagra 4700
Chain
KMC X10 (10-Speed)
Pedals
Composite Flat
Wheels
Rims
Tommaso Corsa TC-40D
Tires
CST Tirent 700x40c All Terrain
Brakes
Brakes
Avid BB5 Disc
Brake Levers
Shimano Tiagra 4700
Cockpit
Stem
Tommaso TRS Ultralight Sport Series
Handlebar
Tommaso TRS Ultralight Sport Series
Headset
1-1/8" Threadless Integrated
Seat
Saddle
WTB Volt - Tommaso Logo
Seatpost
Tommaso TRS Ultralight Race Series Aluminum 27.2mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Rake | 45 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Top Tube Length | 524 mm | 544 mm | 559 mm | 574 mm | 589 mm |
| Seat Tube Angle | 74 ° | 73.5 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 480 mm | 510 mm | 540 mm | 570 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 135 mm | 150 mm | 170 mm | 190 mm | 210 mm |
| Chainstay Length | 409 mm | 409 mm | 409 mm | 409 mm | 409 mm |
| Wheelbase | 972 mm | 988 mm | 998 mm | 1008 mm | 1023 mm |
| Standover Height | 724 mm | 749 mm | 769 mm | 794 mm | 819 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 166 cm | 171 cm | 179 cm | 187 cm |
| Rider Max Height | 169 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Illimitate Disc is part of the Tommaso Illimitate model. 5 bikes variations carry this model name so far. You can get a glimpse at all models from 2021, by clicking on this link.
Model range prices
Tommaso Illimitate Disc 2021 is the most economical model, with a starting price of 1174$. Tommaso Illimitate 2021 on the other hand costs 1175$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Gravel bikes
If you want an acceptable Gravel bike you should know that the average price is 2462$. However, you could also get a good Gravel bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 1174$. In conclusion, this bike price is 109.71% smaller than the price of the average Gravel bike.
Illimitate Disc components
Fork material
Illimitate Disc has a carbon fork, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
When leaving the production line, the Illimitate Disc model has 700c aluminum wheels. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
Nothing is more important on a bike than its ability to brake properly. Tommaso Illimitate Disc is equipped with Mechanical Disc brakes. These brakes are also very popular, and a lot cheaper than hydraulic disk brakes. However, they don’t have the stopping power of hydraulic brakes.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 157 cm – 195 cm (5.15 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
