Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Steel -
Wheels 26" -
Travel Front 100mm -
Fork RockShox Pike DJ
-
Suspension Hardtail -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 170cm
LG
175cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Chromoly
Suspension Fork
RockShox Pike DJ 26, 40mm offset
Rear Shock
N/A
Drivetrain
Rear Derailleur
N/A
Front Derailleur
N/A
Shift Levers
N/A
Cassette
12 tooth single cog
Crank
Samox BMX, 170mm length, 3 piece
Bottom Bracket
Threaded, 73mm
Chain
KMC HL710
Chain Guide
N/A
Pedals
None included
Wheels
Front Hub
Novatec D941SB and D236SBT
Rear Hub
Novatec D941SB and D236SBT
Rims
Kinlin DDT32 26
Tires
Kenda Small Block 8, 60tpi, 26" x 2.1"
Brakes
Brakes
SRAM Level T with 160mm Centerline rotors
Brake Levers
SRAM Level T
Cockpit
Stem
Kore Rivera, 50mm length, 42.5mm
Handlebar
Kore Torsion, 760mm, 31.8mm clamp
Grips
Velo Single Clamp
Headset
FSA No 10, 7B/44, 44mm Zero Stack (Top) / 44mm External (Bottom)
Seat
Saddle
Transition Pivotal
Seatpost
Velo Plastic Pivotal
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | LG |
|---|---|---|
| Stack Reach Ratio | 1.37 mm | 1.29 mm |
| Bottom Bracket Height | 320 mm | 320 mm |
| Stack | 575 mm | 575 mm |
| Reach | 421 mm | 446 mm |
| Top Tube Length | 606 mm | 631 mm |
| Seat Tube Angle | 72 ° | 72 ° |
| Seat Tube Length | 338 mm | 338 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° |
| Head Tube Length | 110 mm | 110 mm |
| Chainstay Length | 394 mm | 394 mm |
| Wheelbase | 1068 mm | 1093 mm |
| Bottom Bracket Drop | 23 mm | 23 mm |
| Standover Height | 689 mm | 695 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 154 cm | 175 cm |
| Rider Max Height | 170 cm | 190 cm |
About this model
PBJ is a Transition Pbj model. 15 bikes variations carry this model name so far. Take a sneak peek at all Transition Pbj bikes models from 2018, by clicking here.
Model range prices
Transition PBJ 2018 is the cheapest bike model and costs 1599$. Transition PBJ Complete 2018 is the most expensive one and costs 1599$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Dirt Jump bikes
If you want an acceptable Dirt Jump bike you should know that the average price is 863$. However, even if your budget is less than the average, you might still be able to get a top-quality Dirt Jump bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2018 and its price was 1599$. Doing a quick comparison, we notice that PBJ price is 85.28% higher than the average cost of a Dirt Jump bike.
PBJ components
Fork
The RockShox Pike DJ is included from the factory. It has a travel distance of 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Wheels size
The PBJ 2018 bike is equipped with 26″ aluminum wheels when leaving the factory. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they provide less traction than 29″ wheels do.
Brakes
Nothing is more important on a bike than its ability to brake properly. Transition PBJ is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
PBJ comes in 2 sizes, that range from 154 cm – 190 cm (5.05 ft – 6.23 ft). In conclusion, you won’t have a problem finding one that suits you.
