Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 150mm -
Travel Rear 130mm -
Fork Fox Performance Elite Float 36
-
Groupset X01 Eagle, Truvativ Descendant Carbon -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
143cm - 160cm
SM
154cm - 170cm
MD
164cm - 182cm
LG
175cm - 190cm
XL
184cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
FOX 36 Float Fit4 Performance Elite
Rear Shock
FOX DPX2 Performance Elite, metric
Drivetrain
Rear Derailleur
SRAM X01 Eagle, 12-Speed
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12-Speed
Cassette
SRAM XG-1275, 10-50 tooth
Crank
SRAM Descendent Carbon, 170mm length
Bottom Bracket
Threaded 73mm
Chain
SRAM GX Eagle
Chain Guide
N/A
Pedals
N/A
Wheels
Front Hub
e*thirteen TRS+
Rear Hub
e*thirteen TRS+
Rims
e*thirteen TRS+
Tires
Maxxis Minion DHF | Maxxis Minion DHR II, 27.5" x 2.3" EXO 3C
Brakes
Brakes
SRAM Code RSC calipers, SRAM Centerline 180mm rotors
Brake Levers
SRAM Code RSC
Cockpit
Stem
Race Face Turbine R, 40mm length
Handlebar
Race Face Turbine R 35, 800mm width
Grips
ODI Elite Flow
Headset
Cane Creek 40 Series, zero-stack
Seat
Saddle
ANVL Forge Stealth Cromo
Seatpost
RockShox Reverb Stealth, 1x remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.47 mm | 1.4 mm | 1.34 mm | 1.3 mm | 1.25 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm | 335 mm | 335 mm |
| Front Center | 707 mm | 736 mm | 765 mm | 794 mm | 823 mm |
| Rake | 37 mm | 37 mm | 37 mm | 36 mm | 36 mm |
| Trail | 125 mm | 125 mm | 125 mm | 126 mm | 126 mm |
| Stack | 595 mm | 604 mm | 613 mm | 623 mm | 632 mm |
| Reach | 406 mm | 431 mm | 456 mm | 481 mm | 506 mm |
| Top Tube Length | 553 mm | 581 mm | 609 mm | 638 mm | 666 mm |
| Seat Tube Angle | 76.6 ° | 76.1 ° | 75.5 ° | 75 ° | 74.6 ° |
| Seat Tube Length | 355 mm | 380 mm | 410 mm | 450 mm | 495 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 431 mm | 431 mm | 431 mm | 431 mm | 431 mm |
| Wheelbase | 1137 mm | 1166 mm | 1195 mm | 1224 mm | 1253 mm |
| Bottom Bracket Drop | 20 mm | 20 mm | 20 mm | 20 mm | 20 mm |
| Standover Height | 681 mm | 681 mm | 691 mm | 701 mm | 716 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 143 cm | 154 cm | 164 cm | 175 cm | 184 cm |
| Rider Max Height | 160 cm | 170 cm | 182 cm | 190 cm | 200 cm |
About this model
Scout X01 belongs to the Transition Scout model. Transition launched 40 bikes of this model so far. Take a sneak peek at all Transition Scout bikes models from 2018, by clicking here.
Model range prices
Transition SCOUT NX 2018 is the most economical model, with a starting price of 2999$. Transition SCOUT XO1 2018 on the other hand costs 4999$, and is the most expensive model.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Trail bikes
Our math shows that the average cost of a dependable Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
When Transition released this model in 2018, its price was 4999$. Comparing this to the average Trail bike price, we see that the price is 80.99% more expensive.
Scout X01 components
Fork
Transition Scout X01 2018 bike is equipped with the Fox Performance Elite Float 36 fork, and has 150mm travel. Bike forks are good shock absorbers and provide a smooth ride and a great experience. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is FOX DPX2 Performance Elite, with a travel distance of 130mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels size
When leaving the production line, the Scout X01 model has 27.5″ aluminum wheels. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Transition Scout X01 bike has 5 sizes, in the range of 143 cm – 200 cm (4.69 ft – 6.56 ft). In conclusion, you won’t have a problem finding one that suits you.
Dropper post
Transition Scout X01 comes with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
