Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset SLX -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
153cm - 166cm
MD
161cm - 176cm
LG
173cm - 188cm
XL
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Platinum Aluminum, tapered head tube, internal derailleur & dropper post routing, proprietary rack mounts, horizontal sliding dropouts, Boost148, 12mm thru axle
Suspension Fork
1120 HCM Carbon, rack and fender mounts, Boost110, 15mm thru axle
Drivetrain
Rear Derailleur
Shimano SLX M7100, long cage
Shift Levers
Shimano SLX M7100, 12 speed
Cassette
Shimano SLX M7100, 10-51, 12 speed
Crank
Size: S, Shimano SLX M7100, 30T alloy ring, Boost (52mm chainline), 170mm length; Size: M, L, XL, Shimano SLX M7100, 30T alloy ring, Boost (52mm chainline), 175mm length
Bottom Bracket
Shimano MT500, 92mm, PressFit
Chain
Shimano SLX M7100, 12 speed
Wheels
Front Hub
Bontrager alloy, 6-bolt, Boost110, 15mm thru axle
Rear Hub
Bontrager alloy, sealed bearing, alloy, 6-bolt, Rapid Drive 108, Shimano MicroSpline freehub, Boost148, 12mm thru axle
Rims
SUNringle Duroc 50 SL, tubeless tape included, 28-hole, 50mm width, presta valve
Tires
Bontrager XR2 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 29x3.00?
Brakes
Brakes
Shimano 4-piston hydraulic disc, MT4100 lever, MT420 caliper
Disk Rotors
Size: S, M, L, XL, Shimano RT56, 6-bolt, 180mm; Size: S, Shimano RT56, 6-bolt, 160mm
Cockpit
Stem
Size: S, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 60mm length; Size: M, L, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 70mm length; Size: XL, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 80mm length
Handlebar
Bontrager Comp, alloy, 31.8mm, 5mm rise, 720mm width
Grips
Bontrager XR Endurance Comp, lock-on
Headset
FSA Integrated, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Seat
Saddle
Bontrager Arvada, hollow chromoly rails, 138mm width
Seatpost
Size: S, Bontrager Line Dropper, 100mm travel, internal routing, 31.6mm, 345mm length; Size: M, L, XL, Bontrager Line Dropper, 125mm travel, internal routing, 31.6mm, 395mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.61 mm | 1.51 mm | 1.43 mm | 1.39 mm |
| Bottom Bracket Height | 314 mm | 315 mm | 315 mm | 315 mm |
| Front Center | 653 mm | 679 mm | 712 mm | 736 mm |
| Rake | 51 mm | 50 mm | 51 mm | 52 mm |
| Trail | 85 mm | 85 mm | 85 mm | 86 mm |
| Stack | 628 mm | 628 mm | 636 mm | 645 mm |
| Reach | 390 mm | 416 mm | 445 mm | 465 mm |
| Top Tube Length | 554 mm | 580 mm | 613 mm | 637 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 394 mm | 419 mm | 470 mm | 521 mm |
| Head Tube Angle | 70.4 ° | 70.4 ° | 70.3 ° | 70.3 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm | 120 mm |
| Chainstay Length | 434 mm | 434 mm | 434 mm | 434 mm |
| Wheelbase | 1076 mm | 1102 mm | 1136 mm | 1160 mm |
| Bottom Bracket Drop | 76 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 772 mm | 785 mm | 786 mm | 786 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 153 cm | 161 cm | 173 cm | 186 cm |
| Rider Max Height | 166 cm | 176 cm | 188 cm | 196 cm |
About this model
1120 is part of the Trek 1120 model. There are 12 bikes that carry this model name. You can easily view all of the Trek 1120 bikes models from 2022, here.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Touring bikes
Our math shows that the average cost of a dependable Touring bike is 1007$. However, you could also get a good Touring bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
At the moment of the release date, Trek 1120 price was 2899$. Comparing this to the average Touring bike price, we see that the price is 187.88% higher.
Touring bikes average weight
The average weight for Touring bikes is 13.35 kg (29.43 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 14.08 kg (31.04 lbs), the 1120 model is a bit heavier than average. In short, the average Touring bike weight is 5.47% lower than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Overview of components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Trek 1120 2022, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The 1120 comes with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
1120 comes in 4 sizes, that range from 153 cm – 196 cm (5.02 ft – 6.43 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the 1120. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
