Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Wheels 26" -
Groupset Tourney -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
WSD Trek Custom Steel w/chromoly seat tube
Drivetrain
Rear Derailleur
Shimano Tourney TX35
Front Derailleur
Shimano Tourney
Shift Levers
Shimano Tourney EF40, 7 speed
Cassette
Shimano TZ31 14-34, 7 speed
Crank
Forged alloy 3 piece, 48/38/28
Pedals
Wellgo nylon platform
Wheels
Rims
Formula FM21 alloy front hub; Formula FM31 alloy rear hub w/Bontrager AT-550 36-hole rims
Tires
Bontrager LT3, 26x2.0"
Brakes
Brakes
Tektro alloy linear-pull brakes w/Shimano Tourney levers
Cockpit
Stem
Bontrager Forged, 25.4mm, 40 degree
Handlebar
Bontrager Riser, 25.4mm, 30mm rise
Headset
1-1/8" threadless
Seat
Saddle
Bontrager SSR WSD
Seatpost
Bontrager SSR, 29.2mm, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 16" | 19.5" |
|---|---|---|---|
| Wheels | 26" | 26" | 26" |
Model Overview
820 WSD belongs to the Trek 820 model. There are 35 bikes that carry this model name. Check out the entire range from 2014 of this model, by clicking this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Crosscountry bikes average price
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Overview of components
Wheels
When leaving the production line, the 820 WSD model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek 820 WSD has Rim brakes installed. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
