Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Groupset XT -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
15.5"
154cm - 169cm
17.5"
166cm - 180cm
18.5"
176cm - 188cm
19.5"
177cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Platinum Aluminum w/semi-integrated head tube, butted & formed top tube, hydroformed down tube w/integrated gusset, bridgeless seatstay, forged race dropouts & replaceable derailleur hanger
Drivetrain
Rear Derailleur
Shimano Deore XT M780 Shadow
Front Derailleur
Shimano Deore XT
Shift Levers
Shimano Deore XT M780, 10 speed
Cassette
Shimano SLX HG81-10 11-36, 10 speed
Crank
Shimano Deore XT M780, 42/32/24
Bottom Bracket
BSA, 73mm, threaded
Pedals
n/a
Wheels
Rims
Bontrager Race Lite Pro TLR Disc wheel system, 15mm front hub, 135x5mm rear hub, 28 hole, center lock, Tubeless Ready
Tires
Bontrager XR1 Team, 26x2.2"
Brakes
Brakes
Shimano Deore XT M785 hydraulic disc brakes
Cockpit
Stem
Bontrager Race X Lite, 31.8mm
Handlebar
Bontrager Race X Lite Low Riser, 31.8mm, 15mm rise, 9 degree sweep
Headset
FSA Orbit Z, 1-1/8" threadless, semi-integrated, semi-cartridge bearings
Seat
Saddle
Bontrager Evoke 2, chromoly rails
Seatpost
Bontrager Race X Lite, 31.6mm, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 154 cm | 166 cm | 176 cm | 177 cm | 186 cm |
| Rider Max Height | 169 cm | 180 cm | 188 cm | 189 cm | 196 cm |
Model Overview
8500 E completes the Trek 8500 model. Trek released 14 bikes variations of this model so far. Take a sneak peek at all Trek 8500 bikes models from 2012, by clicking here.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Crosscountry bikes
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Wheels size
When leaving the production line, the 8500 E model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Nothing is more important on a bike than its ability to brake properly. Trek 8500 E is equipped with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 154 cm – 196 cm (5.05 ft – 6.43 ft). In short, it won’t be difficult to find the right one for you.
