Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Groupset GX, X5 -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
49cm
156cm - 164cm
52cm
161cm - 169cm
54cm
167cm - 175cm
56cm
173cm - 181cm
58cm
179cm - 186cm
61cm
184cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
100 Series Alpha aluminum, rack & fender mounts, 142x12mm thru axle, 73mm threaded bottom bracket
Suspension Fork
920 alloy disc adventure, 15mm thru axle
Drivetrain
Rear Derailleur
SRAM GX, Type 2, long cage
Front Derailleur
SRAM X5, 34.9mm clamp
Shift Levers
Size: 49, 52, 54, 56, 58, 61, SRAM S700, 2-speed; Size: 49, 52, 54, 56, 58, 61, SRAM S700, 10 speed
Cassette
SRAM PG-1030, 11-36, 10 speed
Crank
Size: 49, 52, 54, ProWheel forged alloy, 42/28, 2-piece, 170mm length; Size: 56, 58, 61, ProWheel forged alloy, 42/28, 2-piece, 175mm length
Bottom Bracket
Sealed cartridge, GXP Type
Chain
KMC X10, 10 speed
Wheels
Rims
Bontrager Duster Elite, Tubeless Ready, 100x15mm thru axle
Tires
Bontrager XR1, 29x2.00'' [p18]
Brakes
Disk Rotors
Avid G2 Cleansweep, 160mm, 6-bolt
Cockpit
Stem
Size: 49, Bontrager Elite Basic, 31.8mm, Blendr compatible, 7 degree, 80mm length; Size: 52, Bontrager Elite Basic, 31.8mm, Blendr compatible, 7 degree, 90mm length; Size: 54, 56, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 100mm length; Size: 58, 61, Bontrager Elite, 31.8mm, Blendr compatible, 7 degree, 110mm length
Handlebar
Bontrager Race VR-C, 31.8mm
Headset
FSA Integrated, sealed cartridge bearing, 1-1/8''
Seat
Saddle
Bontrager Evoke
Seatpost
Bontrager alloy, 27.2mm, 12mm offset, 330mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 49cm | 52cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.45 mm | 1.48 mm | 1.53 mm | 1.55 mm | 1.58 mm |
| Bottom Bracket Height | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm | 283 mm |
| Front Center | 621 mm | 623 mm | 628 mm | 637 mm | 648 mm | 655 mm |
| Rake | 55 mm | 55 mm | 55 mm | 56 mm | 54 mm | 55 mm |
| Trail | 75 mm | 72 mm | 68 mm | 67 mm | 67 mm | 65 mm |
| Stack | 562 mm | 573 mm | 589 mm | 614 mm | 633 mm | 648 mm |
| Reach | 391 mm | 394 mm | 398 mm | 401 mm | 408 mm | 411 mm |
| Top Tube Length | 546 mm | 557 mm | 568 mm | 584 mm | 600 mm | 610 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.8 ° | 73.3 ° | 73 ° | 72.8 ° |
| Seat Tube Length | 440 mm | 470 mm | 490 mm | 510 mm | 530 mm | 560 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71 ° | 71.3 ° | 71.3 ° | 71.5 ° |
| Head Tube Length | 95 mm | 105 mm | 120 mm | 145 mm | 165 mm | 180 mm |
| Chainstay Length | 471 mm | 471 mm | 471 mm | 471 mm | 471 mm | 471 mm |
| Wheelbase | 1078 mm | 1080 mm | 1085 mm | 1094 mm | 1106 mm | 1113 mm |
| Bottom Bracket Drop | 85 mm | 85 mm | 85 mm | 85 mm | 85 mm | 85 mm |
| Standover Height | 728 mm | 749 mm | 766 mm | 784 mm | 802 mm | 823 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 156 cm | 161 cm | 167 cm | 173 cm | 179 cm | 184 cm |
| Rider Max Height | 164 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm |
Model Overview
920 is part of the Trek 920 model. Trek launched 14 bikes of this model so far. Take a sneak peek at all Trek 920 bikes models from 2021, by clicking here.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Touring bikes
Our math shows that the average cost of a dependable Touring bike is 1007$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Touring bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
When Trek released this model in 2021, its price was 2099$. Doing a quick comparison, we notice that 920 price is 108.44% higher than the average cost of a Touring bike.
Average weight for Touring bikes
The average weight for Touring bikes is 13.35 kg (29.43 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
920 weighs 12.89 kg (28.42 lbs) and is slightly lighter than the average. In conclusion, the average Touring bike weighs 3.57% more than 920.
Overview of components
Fork material
The fork is made out of aluminum, which is a lighter material. However, it is not as tough, nor durable as steel is.
Wheels size
The 920 2021 bike is equipped with 29″ aluminum wheels when leaving the factory. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
When you want to stop the bike in time, the brakes are vital. The 920 has Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
Sizes
There are 6 sizes available for this model. Rider height can be anywhere between 156 cm – 191 cm (5.12 ft – 6.27 ft). In conclusion, finding one for you shouldn’t be a problem.
