Trek Allant+ 5 Lowstep 2022
2022 E-bike
Estimate price |
3,956$
Weight | 19.26 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Travel Front 45mm -
Fork SunTour MOBIE
-
Groupset Alivio, Altus -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery Bosch Powerpack Performance 500 downtube -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
High-performance hydroformed alloy, internal cable routing, Motor Armour, post-mount disc, 135x5 mm QR
Suspension Fork
SR Suntour Mobie25, 45 mm travel, preload, rebound and lockout, tapered alloy steerer, post-mount disc
Drivetrain
Rear Derailleur
Size: S, M, L, Shimano Alivio M3100, long cage; Size: S, M, L, Shimano Alivio M4000, long cage, 36T max cog
Shift Levers
Shimano Altus M2010, 9-speed
Cassette
Shimano HG200, 11-36, 9-speed
Crank
Size: S, M, ProWheel alloy, 170 mm; Size: L, ProWheel alloy, 175mm
Chain
KMC E9S, 9-speed
Wheels
Front Hub
Bontrager Disc, 32-hole, 6-bolt disc, 15 mm alloy thru-axle
Rear Hub
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Rims
Bontrager Kovee, double-wall, Tubeless Ready, 28-hole, 23 mm width, Presta valve
Tires
Schwalbe G-One, 650Bx57 c
Brakes
Brakes
Shimano MT200 hydraulic disc
Disk Rotors
Shimano RT26, 6-bolt,180 mm
Cockpit
Stem
Size: S, Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 70 mm length; Size: M, Bontrager alloy, 31.8 mm, Blendr-compatible, 7-degree, 80 mm length; Size: L, Bontrager alloy, 31.8 mm clamp, Blendr-compatible, 7-degree, 90 mm length
Handlebar
Alloy lowriser, 31.8 mm, 25 mm rise, 11-degree backsweep, 660 mm width
Grips
Bontrager Satellite Elite, alloy lock-on
Seat
Saddle
Bontrager Commuter Comp
Seatpost
Bontrager alloy, 31.6 mm, 12 mm offset, 330 mm length
Motor & Battery
Motor
Bosch Performance CX, magnesium motor body, 250 watt, 85 Nm, 25 km/h (15.5 mph) max assist, 32 km/h for New Zealand
Battery
Bosch Powerpack Performance 500 downtube
Charger
Bosch standard 4A (220-240 V) charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.62 mm | 1.66 mm | 1.71 mm |
| Bottom Bracket Height | 299 mm | 299 mm | 299 mm |
| Front Center | 634 mm | 645 mm | 656 mm |
| Rake | 45 mm | 45 mm | 45 mm |
| Trail | 89 mm | 86 mm | 83 mm |
| Stack | 604 mm | 630 mm | 660 mm |
| Reach | 372 mm | 379 mm | 386 mm |
| Top Tube Length | 557 mm | 572 mm | 588 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 450 mm | 500 mm | 550 mm |
| Head Tube Angle | 69 ° | 69.5 ° | 70 ° |
| Head Tube Length | 150 mm | 170 mm | 205 mm |
| Chainstay Length | 482 mm | 482 mm | 482 mm |
| Wheelbase | 1109 mm | 1120 mm | 1132 mm |
| Bottom Bracket Drop | 60 mm | 60 mm | 60 mm |
| Standover Height | 592 mm | 582 mm | 571 mm |
| Wheels | 650 | 650 | 650 |
| Rider Min Height | 155 cm | 164 cm | 174 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm |
About this model
Allant+ 5 Lowstep is a Trek E Allantplus model. Trek released 60 e-bikes variations of this model so far. You can get a glimpse at all models from 2022, by clicking on this link.
Model range prices
Trek Allant+ 5 Lowstep 2022 is the cheapest e-bike model and costs 3662$. Trek Allant+ 9.9S Stagger 2022 is the most expensive one and costs 7431$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Commuter e-bikes
According to our math, the average price for a trustworthy Commuter e-bike is 2569$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Commuter e-bike. To sum up, when you purchase your e-bike, make sure to check if it has reviews, and also do some components research.
When Trek released this model in 2022, its price was 3662$. If we compare this with the average Commuter e-bike cost we notice that the price is 42.55% more expensive.
Average weight for Commuter e-bikes
Commuter e-bikes weigh an average of 25.2 kg (55.56 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Weighing 19.26 kg (42.46 lbs), the Allant+ 5 Lowstep model is much lighter than average. In other words, this model is 30.84% lighter than the average Commuter e-bike.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Overview of components
Fork
This e-bike has the SunTour MOBIE fork installed. The fork’s travel is 45mm. Bike forks are great for shock absorption and provide you with a smooth ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Fork material
The fork on this e-bike is made out of aluminum, so there won’t be much extra weight added to the e-bike. However, they are not so stiff as carbon forks are.
Wheels size
The wheels on Allant+ 5 Lowstep are the aluminum type. The 650b wheels are very similar to 700c, with a slight difference in diameter. However, if speed is what you’re after, 700c wheels are a better fit.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Allant+ 5 Lowstep comes with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, these are ideal for anyone.
Sizes
This e-bike is available in 3 sizes. They vary from 155 cm – 186 cm (5.09 ft – 6.1 ft). In short, it won’t be difficult to find the right one for you.
