Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 26" -
Travel Front 100mm -
Fork Manitou
-
Groupset XT, Shimano -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
AC/DC - (Aluminum / Carbon Damping / Composite) - ZR9000 internally and externally butted aluminum main frame, Carbon composite seat and chain stays | Disc Specific | Genesis Geometry
Suspension Fork
Manitou Skareb Super, 100mm travel, TPC Lock-Out
Drivetrain
Rear Derailleur
Shimano XT SGS
Front Derailleur
Shimano LX
Shift Levers
Shimano XT
Cassette
SRAM PG970 11-34T, 9SPD
Crank
Bontrager Race 44/32/22
Pedals
Shimano M505 , clipless
Wheels
Tires
Bontrager ACX 26x2.2 , folding
Brakes
Brakes
Hayes HFX-9, hydraulic disc w/ Hayes
Cockpit
Stem
Bontrager Select OS, 31.8mm clamp, 7 degree rise
Handlebar
Bontrager Select OS, 31.8mm clamp, 630mm width, 25mm rise
Headset
Aheadset, semi-cartridge
Seat
Saddle
Bontrager Race Luxe
Seatpost
Bontrager Select
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
About this model
Big Sur Disc is a Trek Big Sur model. Trek launched 21 bikes of this model so far. Check out the entire range from 2005 of this model, by clicking this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Crosscountry bikes
If you want to purchase a solid Crosscountry bike, it is important to know that the average cost is 1905$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Big Sur Disc components
Fork
The fork installed on this bike is the Manitou model. The travel on this model is 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In short, you should always ensure you have a good fork when purchasing a bike.
Wheels size
The wheels on Big Sur Disc are the 26″ type. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek Big Sur Disc has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
Big Sur Disc comes in 5 sizes, that range from 156 cm – 195 cm (5.12 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
