Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Travel Front 100mm -
Fork Manitou
-
Groupset XT, Deore -
Suspension Hardtail -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Platinum Series ZR9000 double butted aluminum | Genesis Geometry
Suspension Fork
Manitou Black Elite | TPC damping | 80/100mm adjustable travel
Drivetrain
Rear Derailleur
Shimano Deore XT SGS
Front Derailleur
Shimano Deore
Shift Levers
Shimano Deore LX
Cassette
SRAM 7.0 11-32 | 9 speed
Crank
Bontrager Select | 44/32/22
Pedals
Shimano M515 | clipless
Wheels
Rims
Bontrager Superstock Disc OSB wheelsystem | IRC Mythos XC tires
Tires
IRC Mythos XC | 26x2.1
Brakes
Brakes
Hayes HFX Comp Hydraulic disc w/ Hayes Hydraulic
Cockpit
Stem
Bontrager Select
Handlebar
Bontrager Crowbar Sport DB
Headset
Dia-Compe STR | Aheadset
Seat
Saddle
WTB SSTX
Seatpost
Bontrager Sport
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
Model Overview
Big Sur_Disc completes the Trek Big Sur model. There are 21 bikes that carry this model name. You can get a glimpse at all models from 2002, by clicking on this link.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, you could also get a good Crosscountry bike even if you pay a lower amount than the average price. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Overview of components
Fork
The fork installed on this bike is the Manitou model. The travel on this model is 100mm. Bike forks are great for shock absorption and provide you with a smooth ride. To sum it all, when buying a bike, ensure that you look for a fork capable of decent travel.
Wheels
When it comes to wheels, the Big Sur_Disc bike is equipped with the 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The Big Sur_Disc has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, these are ideal for anyone.
Sizes
Big Sur_Disc comes in 4 sizes, that range from 158 cm – 199 cm (5.18 ft – 6.53 ft). In short, you can easily find one that suits you.
