Trek E-Caliber 9.8 GX Gen 1 2021
2021 E-bike
Estimate price |
8,499$
Weight | 16.99 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Front 120mm -
Travel Rear 60mm -
Fork RockShox SID Select+
-
Groupset GX Eagle, e*thirteen -
Suspension Full -
Motor Fazua 250W 60Nm mid-drive -
Battery Fazua Evation battery, 250Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 178cm
LG
175cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon main frame & stays, IsoStrut, tapered head tube, Knock Block, Control Freak internal routing, Boost148, 60mm travel
Suspension Fork
RockShox SID Select+, DebonAir spring, Charger 2 RL damper, tapered steerer, 44mm offset, Boost110, 15mm Maxle Stealth, 120mm travel
Rear Shock
Size: S, Trek IsoStrut, Fox Performance shock, air spring, DPS 2-position remote damper, 235x32.5mm; Size: M, L, XL, Trek IsoStrut, Fox Performance shock, air spring, DPS 2-position remote damper, 235mm x 32.5mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle, 12 speed
Cassette
SRAM Eagle XG-1275, 10-52, 12 speed
Crank
E*thirteen E*spec Race Carbon, 32T, 175mm length
Chain
SRAM GX Eagle, 12 speed
Wheels
Rims
Front: Bontrager Kovee Pro 30 Carbon, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, Rear: Bontrager Kovee Pro 30 Carbon, Tubeless Ready, Rapid Drive 108, 6-bolt, Boost 110, 15mm thru axle
Tires
Bontrager XR3 Team Issue, Tubeless Ready, Inner Strength sidewall, aramid bead, 120tpi, 29x2.40''
Brakes
Brakes
SRAM G2 RSC 4-piston hydraulic disc
Cockpit
Stem
Size: S, M, Bontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 13 degree, 60mm length; Size: L, XL, Bontrager Kovee Pro, 35mm, Knock Block, Blendr compatible, 13 degree, 70mm length
Handlebar
Bontrager Line Pro, OCLV Carbon, 35mm, 15mm rise, 750mm width
Grips
ESI Chunky
Headset
Knock Block Integrated, 62-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom
Seat
Saddle
Bontrager Verse Elite, austenite rails, 145mm width
Seatpost
Size: S, Bontrager Line Elite Dropper, 100mm travel, MaxFlow, internal routing, 31.6mm, 340mm length; Size: M, L, XL, Bontrager Line Elite Dropper, 150mm travel, MaxFlow, internal routing, 31.6mm, 440mm length
Motor & Battery
Motor
Fazua Evation Drive Pack, 20mph max assist
Battery
Fazua Evation battery, 250Wh
Charger
Fazua Evation charger, 90-120V
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.51 mm | 1.41 mm | 1.33 mm | 1.28 mm |
| Bottom Bracket Height | 323 mm | 323 mm | 323 mm | 323 mm |
| Front Center | 684 mm | 723 mm | 754 mm | 776 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 109 mm | 109 mm | 109 mm | 109 mm |
| Stack | 603 mm | 612 mm | 616 mm | 621 mm |
| Reach | 399 mm | 434 mm | 464 mm | 484 mm |
| Top Tube Length | 574 mm | 611 mm | 642 mm | 664 mm |
| Seat Tube Angle | 72.3 ° | 72.6 ° | 72.8 ° | 72.8 ° |
| Seat Tube Length | 394 mm | 419 mm | 470 mm | 508 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 100 mm | 105 mm | 110 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1120 mm | 1159 mm | 1191 mm | 1213 mm |
| Bottom Bracket Drop | 50 mm | 50 mm | 50 mm | 50 mm |
| Standover Height | 762 mm | 762 mm | 762 mm | 762 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 164 cm | 175 cm | 187 cm |
| Rider Max Height | 166 cm | 178 cm | 189 cm | 195 cm |
Model Overview
E-Caliber 9.8 GX Gen 1 belongs to the Trek E E Caliber model. Trek released 26 e-bikes variations of this model so far. Take a sneak peek at all Trek E E Caliber e-bikes models from 2021, by clicking here.
Model range prices
Trek E-Caliber 9.6 2021 is the most affordable e-bike of this model and has a price of 6499$. On the other hand, Trek E-Caliber 9.9 XX1 AXS Gen 1 2021, is the most expensive and costs 12999$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Crosscountry e-bikes
Our math shows that the average cost of a dependable Crosscountry e-bike is 2453$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry e-bike. To make sure you don’t pay a higher amount than normal for your e-bike, always do some components analysis and read reviews.
At the moment of the release date, Trek E-Caliber 9.8 GX Gen 1 price was 8499$. If we compare this with the average Crosscountry e-bike cost we notice that the price is 246.47% more expensive.
Average weight for Crosscountry e-bikes
Crosscountry e-bikes weigh an average of 23.21 kg (51.17 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 16.99 kg (37.46 lbs), the E-Caliber 9.8 GX Gen 1 model is much lighter than average. In short, the average Crosscountry e-bike weight is 36.61% higher than this one.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
E-Caliber 9.8 GX Gen 1 components
Fork
The E-Caliber 9.8 GX Gen 1 comes factory-installed with the RockShox SID Select+ fork. This has a travel range of 120mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
Trek E-Caliber 9.8 GX Gen 1 e-bike has the Size: S model installed, and has a travel of 60mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The E-Caliber 9.8 GX Gen 1 2021 e-bike is equipped with 29″ carbon wheels when leaving the factory. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your e-bike react slower to obstacles you may encounter.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The E-Caliber 9.8 GX Gen 1 comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, your safety is in good hands.
Sizes
E-Caliber 9.8 GX Gen 1 comes in 4 sizes, that range from 155 cm – 195 cm (5.09 ft – 6.4 ft). In short, you can easily find one that suits you.
Dropper post
A dropper post is included with the E-Caliber 9.8 GX Gen 1. Therefore, climbing or descending will be a breeze.
