Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED 22 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ultralight 700 Series OCLV Carbon, ride-tuned performance tube optimization, E2 tapered head tube, BB90, internal cable routing, DuoTrap S compatible, Ride Tuned seatmast
Suspension Fork
Émonda full carbon, carbon E2 asymmetric steerer, carbon dropouts
Drivetrain
Rear Derailleur
SRAM RED 22
Front Derailleur
SRAM RED 22, braze-on
Shift Levers
SRAM RED 22, 11 speed
Cassette
SRAM X-Glide 1190, 11-25, 11 speed
Crank
SRAM RED, 50/34 (compact)
Bottom Bracket
BB90, ceramic
Chain
SRAM RED 22
Wheels
Front Hub
Tune MIG45 (Note: Tune components carry a 198lb/90kg weight limit)
Rear Hub
Tune MAG150 (Note: Tune components carry a 198lb/90kg weight limit)
Rims
Tune Skyline carbon tubular (Note: Tune components carry a 198lb/90kg weight limit)
Tires
Vittoria Crono CS Tubular, 700x22c
Brakes
Brakes
Bontrager Speed Stop, direct mount
Cockpit
Stem
Bontrager XXX Integrated bar/stem, OCLV Carbon, 7 degree
Handlebar
Bontrager XXX Integrated Bar/Stem, OCLV carbon, VR-CF
Grips
Bontrager grip tape
Headset
Cane Creek AER upper, FSA Lightweight cartridge bearing lower, sealed, 1-1/8" top, 1.5" bottom
Seat
Saddle
Tune Komm-Vor Plus, carbon rails, carbon body (Note: Tune components carry a 198lb/90kg weight limit)
Seatpost
Bontrager SLR Ride Tuned Carbon seatmast cap, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 58cm | 62cm |
|---|---|---|---|
| Stack Reach Ratio | 1.32 mm | 1.42 mm | 1.49 mm |
| Bottom Bracket Height | 264 mm | 268 mm | 268 mm |
| Front Center | 575 mm | 591 mm | 607 mm |
| Rake | 45 mm | 40 mm | 40 mm |
| Trail | 61 mm | 56 mm | 55 mm |
| Stack | 508 mm | 569 mm | 608 mm |
| Reach | 385 mm | 402 mm | 409 mm |
| Top Tube Length | 524 mm | 575 mm | 600 mm |
| Seat Tube Angle | 74.6 ° | 73 ° | 72.5 ° |
| Seat Tube Length | 453 mm | 553 mm | 593 mm |
| Head Tube Angle | 72.1 ° | 73.8 ° | 73.9 ° |
| Head Tube Length | 100 mm | 160 mm | 200 mm |
| Chainstay Length | 412 mm | 413 mm | 414 mm |
| Wheelbase | 976 mm | 994 mm | 1012 mm |
| Bottom Bracket Drop | 72 mm | 68 mm | 68 mm |
| Standover Height | 698 mm | 785 mm | 822 mm |
| Wheels | 700 | 700 | 700 |
About this model
Émonda SLR 10 completes the Trek Emonda model. 251 bikes variations carry this model name so far. Check out the entire range from 2017 of this model, by clicking this link.
Model range prices
Trek Émonda 650 2017 is the most affordable bike of this model and has a price of 1099$. On the other hand, Trek Émonda SLR 10 2017, is the most expensive and costs 14999$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Race bikes average price
According to our calculations, the average cost of a Race bike that is reliable is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Furthermore, this bike was made available in 2017 for 14999$. If we compare this with the average Race bike cost we notice that the price is 347.73% more expensive.
Internal Cable Routing
Another thing to mention, is the internal cable routing of this bike. In conclusion, this helps you too, keep the bike cables in mint condition, and also it looks better. No more cables, surrounding the bike.
Émonda SLR 10 components
Fork material
When it comes to the fork, this bike has a carbon one, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels size
As for the wheels, Trek Émonda SLR 10 2017, has a 700c carbon model. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Émonda SLR 10 has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
