Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED 22 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
50cm
157cm - 164cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
60cm
183cm - 191cm
62cm
188cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ultralight 700 Series OCLV Carbon, ride-tuned performance tube optimization, E2, BB90, internal cable routing, 3S chain keeper, DuoTrap S compatible, Ride Tuned seatmast, 690g (56cm, weight varies by frame size)
Suspension Fork
Émonda full carbon, E2 asymmetric steerer, carbon dropouts
Drivetrain
Rear Derailleur
SRAM RED 22
Front Derailleur
SRAM RED 22, braze-on
Shift Levers
SRAM RED 22, 11 speed
Cassette
SRAM X-Glide 1190, 11-25, 11 speed
Crank
SRAM Red, 50/34 (compact)
Bottom Bracket
BB90, 90.5mm, press-fit
Wheels
Tires
Vittoria Crono CS Tubular, 700x22c
Brakes
Brakes
Bontrager Speed Stop
Cockpit
Stem
Bontrager XXX integrated bar/stem, OCLV Carbon, 7 degree
Handlebar
Bontrager XXX Integrated bar/stem, OCLV Carbon, VR-CF
Headset
Cane Creek AER upper, FSA Lightweight cartridge bearing lower, sealed, 1-1/8" top, 1.5" bottom
Seat
Saddle
Tune Komm-Vor Plus, carbon rails, carbon body
Seatpost
Bontrager SLR Ride Tuned Carbon seatmast cap, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm | 188 cm |
| Rider Max Height | 164 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm | 195 cm |
Model Overview
Émonda SLR 10 H1 is a Trek Emonda model. Trek released 251 bikes variations of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Race bikes average price
Our math shows that the average cost of a dependable Race bike is 3350$. However, you could also get a good Race bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Fork material
Émonda SLR 10 H1 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
As for the wheels, Trek Émonda SLR 10 H1 2015, has a 700c model. These wheels are the most used kind for road bikes in general. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Émonda SLR 10 H1 comes with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Trek Émonda SLR 10 H1 bike has 7 sizes, in the range of 157 cm – 195 cm (5.15 ft – 6.4 ft). In conclusion, finding one for you shouldn’t be a problem.
