Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset RED 22 -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Rim
Sizing
Recommended size guide.
50cm
157cm - 164cm
52cm
161cm - 169cm
54cm
166cm - 175cm
56cm
172cm - 181cm
58cm
178cm - 186cm
60cm
183cm - 191cm
62cm
188cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Ultralight 700 Series OCLV Carbon, ride-tuned performance tube optimization, E2 tapered head tube, BB90, internal cable routing, DuoTrap S compatible, Ride Tuned seatmast
Suspension Fork
Émonda full carbon, carbon E2 asymmetric steerer, carbon dropouts
Drivetrain
Rear Derailleur
SRAM RED 22
Front Derailleur
SRAM RED 22, braze-on
Shift Levers
SRAM RED 22, 11 speed
Cassette
SRAM X-Glide 1190, 11-25, 11 speed
Crank
SRAM RED, 50/34 (compact)
Bottom Bracket
BB90, 90.5mm, press-fit
Wheels
Rims
Tune MIG45 front hub, Tune MAG150 rear hub, Tune Skyline carbon tubular rims, Sapim CX-Ray spokes
Tires
Vittoria Crono CS Tubular, 700x22c
Brakes
Brakes
Bontrager Speed Stop, direct mount
Cockpit
Stem
Bontrager XXX Integrated bar/stem, OCLV Carbon, 7 degree
Handlebar
Bontrager XXX Integrated Bar/Stem, OCLV carbon, VR-CF
Headset
Cane Creek AER upper, FSA Lightweight cartridge bearing lower, sealed, 1-1/8" top, 1.5" bottom
Seat
Saddle
Tune Komm-Vor Plus, carbon rails, carbon body (Note: Tune components carry a 198lb/90kg weight limit)
Seatpost
Bontrager SLR Ride Tuned Carbon seatmast cap, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 50cm | 52cm | 54cm | 56cm | 58cm | 60cm | 62cm |
|---|---|---|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 157 cm | 161 cm | 166 cm | 172 cm | 178 cm | 183 cm | 188 cm |
| Rider Max Height | 164 cm | 169 cm | 175 cm | 181 cm | 186 cm | 191 cm | 195 cm |
Model Overview
Émonda SLR 10 H1 is part of the Trek Emonda model. Trek launched 251 bikes of this model so far. You can get a glimpse at all models from 2016, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Race bikes average price
If you want to purchase a solid Race bike, it is important to know that the average cost is 3350$. However, even if your budget is less than the average, you might still be able to get a top-quality Race bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork material
Émonda SLR 10 H1 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels
The wheels on Émonda SLR 10 H1 are the 700c carbon type. These are the most popular wheels for road, aero, gravel, cyclocross, race, and gravel bikes. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Nothing is more important on a bike than its ability to brake properly. Trek Émonda SLR 10 H1 is equipped with Rim brakes. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
Sizes
Émonda SLR 10 H1 comes in 7 sizes, that range from 157 cm – 195 cm (5.15 ft – 6.4 ft). In conclusion, you won’t have a problem finding one that suits you.
