Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset X1 -
Suspension Hardtail -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
14.5"
137cm - 155cm
15.5"
153cm - 167cm
17.5"
161cm - 176cm
19.5"
173cm - 188cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Platinum Aluminum, E2 tapered head tube, internal derailleur and dropper post routing, 100mm threaded BB, low-direct front derailleur mount, 170mm Closed Convert dropouts
Drivetrain
Rear Derailleur
SRAM X1, Type 2
Shift Levers
SRAM X1, 11 speed
Cassette
SRAM XG-1180, 10-42, 11 speed
Crank
SRAM X1 1000 X-Sync, 30T
Bottom Bracket
BSA, 100mm, threaded
Wheels
Rims
Bontrager Jackalope Tubeless Ready, 80mm rim, 150x15 front, 170x12 rear
Tires
Bontrager Hodag, aramid bead, 26x3.8"
Brakes
Brakes
Avid DB 3 hydraulic disc
Cockpit
Stem
Bontrager Race Lite, 31.8mm, 7 degree
Handlebar
Bontrager Race Lite Riser, 31.8mm, 15mm rise
Headset
FSA IS-2, E2, alloy cartridge
Seat
Saddle
Bontrager Evoke 2, chromoly rails
Seatpost
Bontrager Rhythm Elite, 2-bolt clamp, 31.6mm, zero offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 15.5" | 17.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 137 cm | 153 cm | 161 cm | 173 cm | 186 cm |
| Rider Max Height | 155 cm | 167 cm | 176 cm | 188 cm | 196 cm |
Model Overview
Farley 8 is a Trek Farley model. Trek launched 70 bikes of this model so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fatbike bikes
According to our math, the average price for a trustworthy Fatbike bike is 1743$. However, this doesn’t mean that if you spend less money on a Fatbike bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Overview of components
Wheels
When leaving the production line, the Farley 8 model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, you will need increased suspension than in the case of 29″ wheels.
Brakes
Nothing is more important on a bike than its ability to brake properly. Trek Farley 8 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Sizes
Trek Farley 8 bike has 5 sizes, in the range of 137 cm – 196 cm (4.49 ft – 6.43 ft). In short, you can easily find one that suits you.
