Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 27.5"
Sizing
Recommended size guide.
15.5"
153cm - 167cm
17.5"
170cm - 184cm
19.5"
176cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon, tapered head tube, internal derailleur & dropper post routing, PressFit 121mm BB, 197x12mm adjustable horizontal sliding dropouts
Suspension Fork
Farley full carbon, tapered carbon steerer, OCLV Carbon lowers, 490mm axle-to-crown, 15x150mm thru axle
Drivetrain
Bottom Bracket
BB86/BB92, 121mm, press-fit
Cockpit
Headset
FSA IS-2, 1-1/8'' top, 1.5'' bottom
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 19.5" | 21.5" |
|---|---|---|---|---|
| Stack Reach Ratio | 1.58 mm | 1.47 mm | 1.41 mm | 1.37 mm |
| Bottom Bracket Height | 321 mm | 321 mm | 321 mm | 321 mm |
| Front Center | 645 mm | 672 mm | 711 mm | 724 mm |
| Rake | 50 mm | 50 mm | 51 mm | 51 mm |
| Trail | 94 mm | 94 mm | 94 mm | 94 mm |
| Stack | 595 mm | 595 mm | 613 mm | 613 mm |
| Reach | 377 mm | 404 mm | 435 mm | 448 mm |
| Top Tube Length | 561 mm | 588 mm | 625 mm | 638 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 394 mm | 419 mm | 470 mm | 521 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 100 mm | 100 mm | 120 mm | 120 mm |
| Chainstay Length | 449 mm | 449 mm | 449 mm | 449 mm |
| Wheelbase | 1086 mm | 1113 mm | 1152 mm | 1165 mm |
| Bottom Bracket Drop | 67 mm | 67 mm | 67 mm | 67 mm |
| Standover Height | 757 mm | 751 mm | 770 mm | 768 mm |
| Wheels | 27" | 27" | 27" | 27" |
| Rider Min Height | 153 cm | 170 cm | 176 cm | 186 cm |
| Rider Max Height | 167 cm | 184 cm | 189 cm | 196 cm |
Model Overview
Farley C Frameset belongs to the Trek Farley model. 70 frames variations carry this model name so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Trek Farley AL Frameset 2023 is the most affordable frame of this model and has a price of 1499$. On the other hand, Trek Farley C Frameset 2023, is the most expensive and costs 2599$.
Safety
Take safety seriously when you ride your bike, and always wear your helmet. Moreover, don’t ride on the sidewalk. This is actually against the law in some states and can be dangerous for both you and pedestrians.
Average price for Fatbike frames
If you want to purchase a solid Fatbike frame, it is important to know that the average cost is 1277$. However, this doesn’t mean that if you spend less money on a Fatbike frame, you couldn’t get a decent one. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
This frame was released in 2023 and its price was 2599$. Doing a quick comparison, we notice that Farley C Frameset price is 103.52% more expensive than the average cost of a Fatbike frame.
Internal Cable Routing
It’s also important to mention the internal cable routing that this frame has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Farley C Frameset components
Fork material
The fork is made out of carbon, so, it’s a great addition to the frame’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Sizes
There are 4 sizes available for this model. Rider height can be anywhere between 153 cm – 196 cm (5.02 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
