Trek Farley EX Frameset 2022
2022 Mountain
Estimate price |
3,629$
Weight | 2.78 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Rear 120mm -
Suspension Full
Sizing
Recommended size guide.
MD
161cm - 176cm
LG
173cm - 188cm
XL
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon main frame, alloy stays, tapered head tube, Control Freak internal routing, Carbon Armor, magnesium rocker link, ABP, 197x12mm thru axle, 120mm travel
Rear Shock
Fox Performance Float EVOL, RE:aktiv 3-position damper, tuned by Trek Suspension Lab, 7.25x1.875''
Cockpit
Headset
FSA IS-2, 1-1/8'' top, 1.5'' bottom
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.41 mm | 1.35 mm | 1.32 mm |
| Bottom Bracket Height | 352 mm | 352 mm | 352 mm |
| Front Center | 706 mm | 733 mm | 760 mm |
| Rake | 52 mm | 49 mm | 52 mm |
| Trail | 124 mm | 124 mm | 124 mm |
| Stack | 605 mm | 614 mm | 628 mm |
| Reach | 429 mm | 455 mm | 474 mm |
| Top Tube Length | 606 mm | 635 mm | 658 mm |
| Seat Tube Angle | 67 ° | 67 ° | 67 ° |
| Seat Tube Length | 420 mm | 470 mm | 521 mm |
| Head Tube Angle | 68.8 ° | 68.8 ° | 68.8 ° |
| Head Tube Length | 105 mm | 115 mm | 130 mm |
| Chainstay Length | 446 mm | 446 mm | 446 mm |
| Wheelbase | 1151 mm | 1178 mm | 1205 mm |
| Bottom Bracket Drop | 24 mm | 24 mm | 24 mm |
| Standover Height | 779 mm | 758 mm | 764 mm |
| Wheels | 27" | 27" | 27" |
| Rider Min Height | 161 cm | 173 cm | 186 cm |
| Rider Max Height | 176 cm | 188 cm | 196 cm |
Model Overview
Farley EX Frameset is a Trek Farley model. Trek launched 70 frames of this model so far. You can easily view all of the Trek Farley frames models from 2022, here.
Model range prices
The most economical model, the Trek Farley AL Frameset 2022 has a starting price of 1119$. Trek Farley EX Frameset 2022 on the other hand is the most expensive at 3629$.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Fatbike frames average price
If you want an acceptable Fatbike frame you should know that the average price is 1277$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Fatbike frame. In short, before purchasing your ideal frame do some research about its components, and also check for reviews online.
At the moment of the release date, Trek Farley EX Frameset price was 3629$. If we compare this with the average Fatbike frame cost we notice that the price is 184.18% more expensive.
Average weight for Fatbike frames
The average weight for Fatbike frames is 2.73 kg (6.02 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Farley EX Frameset weighs 2.78 kg (6.13 lbs) and is slightly heavier than the average. In short, the average Fatbike frame weight is 1.83% lower than this one.
Internal Cable Routing
It’s also important to mention the internal cable routing that this frame has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Farley EX Frameset components
Rear Shock
As for the rear shock, this frame has the Fox Performance Float EVOL model, with a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Sizes
This frame is available in 3 sizes. They vary from 161 cm – 196 cm (5.28 ft – 6.43 ft). In conclusion, it won’t take much to find one that’s right for you.
