Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset X7, Deore -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
15.5"
154cm - 169cm
17.5"
166cm - 180cm
18.5"
176cm - 188cm
19.5"
177cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Red Aluminum w/ABP Race, Full Floater, E2 tapered head tube, magnesium EVO Link, oversized pivot bearings, replaceable derailleur hanger, 120mm travel
Drivetrain
Rear Derailleur
SRAM X.7
Front Derailleur
Shimano Deore
Shift Levers
SRAM X.5 trigger
Cassette
SRAM PG950 11-32, 9 speed
Crank
Shimano M542 44/32/22
Pedals
Shimano M505, clipless
Wheels
Rims
Bontrager Select front hub, M525-L rear hub; Bontrager Duster rims
Tires
Bontrager XDX, 26x2.2"
Brakes
Brakes
Avid Juicy 3.5, hydraulic disc
Cockpit
Stem
Bontrager Race Lite, 7 degree
Handlebar
Bontrager Race Riser, 40mm rise
Headset
FSA NO.57E, E2, ACB sealed bearings
Seat
Saddle
Bontrager Race
Seatpost
Bontrager Race, 31.6mm, 5mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 154 cm | 166 cm | 176 cm | 177 cm | 186 cm |
| Rider Max Height | 169 cm | 180 cm | 188 cm | 189 cm | 196 cm |
About this model
Fuel EX 7 is part of the Trek Fuel model. 277 bikes variations carry this model name so far. Take a sneak peek at all Trek Fuel bikes models from 2010, by clicking here.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, even though the average price of a Trail bike is lower, you might still be able to get a top-quality bike. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Fuel EX 7 components
Rear Shock
Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The Fuel EX 7 2010 bike is equipped with 26″ aluminum wheels when leaving the factory. These wheels give you great handling over your bike. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fuel EX 7 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Fuel EX 7 comes in 5 sizes, that range from 154 cm – 196 cm (5.05 ft – 6.43 ft). In conclusion, it won’t take much to find one that’s right for you.
