Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset XT -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
15.5"
154cm - 169cm
17.5"
166cm - 180cm
18.5"
176cm - 188cm
19.5"
177cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Black Carbon w/R1i Trail Tuned Suspension, ABP pivot, Full Floater, Aluminum EVO Link, Hi/Lo chainstays, oversized sealed bearings, 120mm rear wheel travel
Drivetrain
Rear Derailleur
Shimano Deore XT "Shadow"
Front Derailleur
Shimano Deore XT
Shift Levers
Shimano Deore XT, 9 speed
Cassette
SRAM PG970 11-32, 9 speed
Crank
Shimano Deore XT 44/32/22
Bottom Bracket
BSA, 73mm, threaded
Pedals
n/a
Wheels
Rims
Bontrager Race Lite
Tires
Bontrager Jones XR, 26x2.2/2.25"; 120 tpi, folding
Brakes
Brakes
Shimano XT, hydraulic disc; 180mm rotors (160 mm rear rotor on 15.5, 17.5, 18.5" sizes)
Cockpit
Stem
Bontrager Race X Lite, 7 degree, 31.8mm
Handlebar
Bontrager Race X Lite, 40mm rise, 31.8mm
Headset
Cane Creek S-3 w/cartridge bearings, sealed
Seat
Saddle
Bontrager Race Lite
Seatpost
Bontrager Race Lite
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 154 cm | 166 cm | 176 cm | 177 cm | 186 cm |
| Rider Max Height | 169 cm | 180 cm | 188 cm | 189 cm | 196 cm |
Model Overview
Fuel EX 9.0 is part of the Trek Fuel model. 277 bikes variations carry this model name so far. You can get a glimpse at all models from 2008, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Fuel EX 9.0 components
Rear Shock
Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels size
As for the wheels, Trek Fuel EX 9.0 2008, has a 26″ aluminum model. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fuel EX 9.0 has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Fuel EX 9.0 comes in 5 sizes, that range from 154 cm – 196 cm (5.05 ft – 6.43 ft). In short, you can easily find one that suits you.
