Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset X0, XT -
Suspension Full -
Drivetrain 3 × 9 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
15.5"
154cm - 169cm
17.5"
166cm - 180cm
18.5"
176cm - 188cm
19.5"
177cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Red Aluminum w/ABP Race, Full Floater, E2 tapered head tube, magnesium EVO Link, oversized pivot bearings, replaceable derailleur hanger, 120mm travel
Drivetrain
Rear Derailleur
SRAM X.0
Front Derailleur
Shimano Deore XT
Shift Levers
SRAM X.9 trigger
Cassette
SRAM PG970 11-32, 9 speed
Crank
Shimano Deore XT 44/32/22
Bottom Bracket
BSA, 73mm, threaded
Pedals
Crank Brothers Custom Candy C
Wheels
Rims
Bontrager Rhythm Elite Disc wheel system, 6 bolt, tubeless ready
Tires
Bontrager XDX, 26x2.2"
Brakes
Brakes
Avid Elixir R, hydraulic disc
Cockpit
Stem
Bontrager Race Lite, 7 degree
Handlebar
Bontrager Race Lite, 40mm rise
Headset
FSA NO.57E, E2, ACB sealed bearings
Seat
Saddle
Bontrager Race Lite
Seatpost
Bontrager Race Lite, 31.6mm, 5mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 154 cm | 166 cm | 176 cm | 177 cm | 186 cm |
| Rider Max Height | 169 cm | 180 cm | 188 cm | 189 cm | 196 cm |
Model Overview
Fuel EX 9 belongs to the Trek Fuel model. 277 bikes variations carry this model name so far. Take a sneak peek at all Trek Fuel bikes models from 2010, by clicking here.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Fuel EX 9 components
Rear Shock
Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Fuel EX 9 2010 bike is equipped with 26″ aluminum wheels when leaving the factory. Being a little smaller, these wheels will fit both small and tall riders. However, they provide less traction than 29″ wheels do.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, you can ride your bike with confidence.
Sizes
Fuel EX 9 comes in 5 sizes, that range from 154 cm – 196 cm (5.05 ft – 6.43 ft). In short, it won’t be difficult to find the right one for you.
