Trek Fuel EX 9.8 27.5 Plus 2017
2017 Mountain
Estimate price |
5,299$
Weight | 12.93 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Performance Float 34
-
Groupset XT -
Suspension Full -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
15.5"
154cm - 169cm
17.5"
166cm - 180cm
18.5"
176cm - 188cm
19.5"
177cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon main frame & seatstay, alloy chainstay, ABP, Boost148, Knock Block steerer stop, Full Floater, EVO link, E2 tapered head tube, Mino Link, Control Freak internal routing, Carbon Armor, PF92, ISCG 05, G2 Geometry, 130mm travel
Suspension Fork
Fox Performance 34 Float, GRIP 3-position damper, E2 tapered steerer, Boost110, G2 Geometry w/51mm offset, 140mm travel
Drivetrain
Rear Derailleur
Shimano Deore XT, Shadow Plus
Front Derailleur
Shimano Deore XT, high direct mount
Shift Levers
Shimano Deore XT M8000, 11 speed
Cassette
Shimano Deore XT, 11-40, 11 speed
Crank
Shimano Deore XT, 36/26
Bottom Bracket
PF92
Chain
Shimano Deore XT
Wheels
Front Hub
DT Swiss 350 centerlock disc, Boost110
Rear Hub
DT Swiss 350 centerlock, Boost148
Rims
SUNringlé Duroc 40 SL 28-hole (tubeless strips and valves included)
Tires
Bontrager Chupacabra, Tubeless Ready, Inner Strength sidewalls, aramid bead, 27.5x2.80"
Brakes
Brakes
Shimano Deore XT hydraulic disc
Cockpit
Stem
Bontrager Line Pro, Knock Block, 35mm, 0 degree
Handlebar
Bontrager Line Pro, OCLV Carbon, 35mm, 15mm rise, 750mm width
Grips
Bontrager Race Lite, lock-on
Headset
Knock Block Integrated, cartridge bearing, sealed, 1-1/8" top, 1.5" bottom
Seat
Saddle
Bontrager Evoke 3, titanium rails
Seatpost
RockShox Reverb Stealth, 2-bolt head, 31.6mm, zero offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.53 mm | 1.41 mm | 1.35 mm | 1.31 mm | 1.27 mm |
| Bottom Bracket Height | 325 mm | 325 mm | 325 mm | 325 mm | 325 mm |
| Front Center | 690 mm | 725 mm | 742 mm | 757 mm | 783 mm |
| Rake | 44 mm | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 102 mm | 102 mm | 102 mm | 102 mm | 102 mm |
| Stack | 601 mm | 600 mm | 600 mm | 600 mm | 609 mm |
| Reach | 393 mm | 427 mm | 444 mm | 459 mm | 481 mm |
| Top Tube Length | 559 mm | 594 mm | 611 mm | 626 mm | 651 mm |
| Seat Tube Angle | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° | 74.2 ° |
| Seat Tube Length | 394 mm | 419 mm | 440 mm | 470 mm | 510 mm |
| Head Tube Angle | 67.2 ° | 67.2 ° | 67.2 ° | 67.2 ° | 67.2 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm | 110 mm |
| Chainstay Length | 427 mm | 427 mm | 427 mm | 427 mm | 427 mm |
| Wheelbase | 1115 mm | 1150 mm | 1167 mm | 1182 mm | 1208 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 761 mm | 741 mm | 736 mm | 731 mm | 741 mm |
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 166 cm | 176 cm | 177 cm | 186 cm |
| Rider Max Height | 169 cm | 180 cm | 188 cm | 189 cm | 196 cm |
Model Overview
Fuel EX 9.8 27.5 Plus completes the Trek Fuel model. Trek launched 277 bikes of this model so far. You can easily view all of the Trek Fuel bikes models from 2017, here.
Model range prices
Trek Fuel EX Jr 2017 is the most economical model, with a starting price of 1889$. Trek Fuel EX 9.9 29 2017 on the other hand costs 8399$, and is the most expensive model.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Trail bikes average price
According to our math, the average price for a trustworthy Trail bike is 2762$. However, this doesn’t mean that if you spend less money on a Trail bike, you couldn’t get a decent one. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5299$. Doing a quick comparison, we notice that Fuel EX 9.8 27.5 Plus price is 91.85% more expensive than the average cost of a Trail bike.
Average weight for Trail bikes
Trail bikes have an average weight of 12.98 kg (28.62 lbs). An easier bike will give you a big advantage in climbs. However, a heavier bike can gain speed when you descend.
Weighing 12.93 kg (28.51 lbs), the Fuel EX 9.8 27.5 Plus model is slightly lighter than average. In short, the average Trail bike weight is 0.39% higher than this one.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Fuel EX 9.8 27.5 Plus components
Fork
This bike has the Fox Performance Float 34 fork installed. The fork’s travel is 140mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The Fuel EX 9.8 27.5 Plus 2017 bike is equipped with 27.5″ aluminum wheels when leaving the factory. The 27.5″ wheels are a great choice for smaller riders. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek Fuel EX 9.8 27.5 Plus has Hydraulic Disc brakes installed. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
This bike is available in 5 sizes. They vary from 154 cm – 196 cm (5.05 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
The Trek model is also equipped with a dropper post. Therefore, climbing or descending will be a breeze.
