Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 26" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset XX -
Suspension Full -
Drivetrain 2 × 10 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
15.5"
154cm - 169cm
17.5"
166cm - 180cm
18.5"
176cm - 188cm
19.5"
177cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon main frame, seatstay & chainstay, Carbon Armor, ABP Convert, Full Floater, E2 tapered head tube, front derailleur internal cable routing, magnesium EVO Link, replaceable derailleur hanger, 120mm travel
Drivetrain
Rear Derailleur
SRAM XX
Front Derailleur
SRAM XX
Shift Levers
SRAM XX, 10 speed
Cassette
SRAM XX 11-36, 10 speed
Crank
SRAM XX, 39/26
Pedals
n/a
Wheels
Rims
DT Swiss XM 1550 Tricon, 15mm front hub, 142x12mm rear hub; 24-hole, center lock, tubeless rims (no spoke holes)
Tires
Bontrager XR4 Team, 26x2.2"
Brakes
Brakes
Avid XX hydraulic disc brakes
Cockpit
Stem
Bontrager Race XXX Lite, 31.8mm
Handlebar
Bontrager Race X Lite Carbon Low Riser, 31.8mm, 15mm rise, 9 degree sweep
Headset
Cane Creek IS-3, E2, alloy cartridge
Seat
Saddle
Bontrager Evoke 4, titanium rails
Seatpost
Bontrager Race XXX Lite, 31.6mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 154 cm | 166 cm | 176 cm | 177 cm | 186 cm |
| Rider Max Height | 169 cm | 180 cm | 188 cm | 189 cm | 196 cm |
About this model
Fuel EX 9.9 is part of the Trek Fuel model. There are 277 bikes that carry this model name. You can get a glimpse at all models from 2012, by clicking on this link.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
According to our calculations, the average cost of a Trail bike that is reliable is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In short, before purchasing your ideal bike do some research about its components, and also check for reviews online.
Internal Cable Routing
This bike has an internal cable routing. As a result, this helps to preserve the bike’s cables. No more cables around your bike.
Fuel EX 9.9 components
Rear Shock
Rear shocks improve riding comfort and give you greater control over all terrains. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
When leaving the production line, the Fuel EX 9.9 model has 26″ aluminum wheels. These wheels give you great handling over your bike. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, your safety is in good hands.
Sizes
Fuel EX 9.9 comes in 5 sizes, that range from 154 cm – 196 cm (5.05 ft – 6.43 ft). In conclusion, you won’t have a problem finding one that suits you.
