Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" -
Travel Front 120mm -
Travel Rear 120mm -
Groupset XTR -
Suspension Full -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
15.5"
154cm - 169cm
17.5"
166cm - 180cm
18.5"
176cm - 188cm
19.5"
177cm - 189cm
21.5"
186cm - 196cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon main frame & stays, Carbon Armor, ABP Convert, Full Floater, E2 tapered head tube, BB95, internal derailleur & dropper post routing, ISCG 05 mount, magnesium EVO link, 120mm travel
Drivetrain
Rear Derailleur
Shimano XTR, Shadow Plus
Shift Levers
Shimano XTR, 11 speed
Cassette
Shimano XTR, 11-40, 11 speed
Crank
Shimano XTR, 32T
Bottom Bracket
BB95, 95.5mm, press-fit
Wheels
Rims
Bontrager Rhythm Elite Tubeless Ready w/TLR strips, RapidDrive, Stacked Lacing, 142x12 rear, 15mm front
Tires
Bontrager XR3 Team Issue, Tubeless Ready, 27.5x2.35" front, 27.5x2.20" rear
Brakes
Brakes
Shimano XTR Trail hydraulic disc
Cockpit
Stem
Bontrager XXX, Carbon, 31.8mm, 7 degree
Handlebar
Bontrager Race X Lite Carbon Riser, 31.8mm, 15mm rise
Headset
Cane Creek IS-3, E2, carbon cartridge
Seat
Saddle
Bontrager Evoke RXL Carbon, carbon rails
Seatpost
RockShox Reverb Stealth, 2-bolt head, 31.6mm, zero offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" | 17.5" | 18.5" | 19.5" | 21.5" |
|---|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 154 cm | 166 cm | 176 cm | 177 cm | 186 cm |
| Rider Max Height | 169 cm | 180 cm | 188 cm | 189 cm | 196 cm |
Model Overview
Fuel EX 9.9 27.5 is part of the Trek Fuel model. 277 bikes variations carry this model name so far. You can get a glimpse at all models from 2015, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Fuel EX 9.9 27.5 components
Rear Shock
Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels
The Fuel EX 9.9 27.5 2015 bike is equipped with 27.5″ aluminum wheels when leaving the factory. 27.5″ wheels will reach higher speeds than smaller-sized wheels. However, these wheels have a slower top speed if you compare them to 29″ wheels.
Brakes
When you want to stop the bike in time, the brakes are vital. The Fuel EX 9.9 27.5 has Hydraulic Disc brakes. Hydraulic disc brakes are perfect for mountain biking, road cycling, and commuting. To sum up, your safety is in good hands.
Sizes
There are 5 sizes available for this model. Rider height can be anywhere between 154 cm – 196 cm (5.05 ft – 6.43 ft). In conclusion, finding one for you shouldn’t be a problem.
Dropper post
A dropper post is included with the Fuel EX 9.9 27.5. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
