Trek Fuel EX 9.9 29 2019
2019 Mountain
Estimate price |
7,799$
Weight | 12.19 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 29" -
Travel Front 130mm -
Travel Rear 130mm -
Fork Fox Factory Float 34
-
Groupset X01 Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon main frame & stays, ABP, Boost148, Knock Block steerer stop, Full Floater, EVO link, tapered head tube, Mino Link, Control Freak internal routing, Carbon Armor, PF92, ISCG 05, G2 Geometry, 130mm travel
Suspension Fork
Fox Factory 34 Float, FIT4 3-position damper, tapered steerer, Kashima Coat, Boost110, G2 Geometry w/51mm offset, 130mm travel
Rear Shock
FOX Factory Float EVOL, RE:aktiv with Thru Shaft, Kashima Coat, 210mm x 52.5mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle, Roller Bearing Clutch
Front Derailleur
N/A
Shift Levers
SRAM X01 Eagle, 12 speed
Cassette
SRAM XG-1275 Eagle, 10-50, 12 speed
Crank
SRAM X01 Eagle carbon DUB, 32T Direct Mount
Bottom Bracket
SRAM DUB Press Fit, 92mm
Chain
SRAM GX Eagle
Chain Guide
None included
Pedals
Not included
Wheels
Front Hub
Rapid Drive, boost 110mm front, boost 148mm rear
Rear Hub
Rapid Drive, boost 110mm front, boost 148mm rear
Rims
Bontrager Line Carbon 30, Tubeless Ready, 54T Rapid Drive, Boost110 front, Boost148 rear, tubeless strips included, valves sold separately
Spokes
DT Swiss Aerolite14/17G spokes with Alpina alloy locking nipples
Tires
Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, 120tpi, aramid bead, 29x2.40?
Brakes
Brakes
Shimano Deore XT M8020 4-piston hydraulic disc
Brake Levers
Shimano Deore XT
Cockpit
Stem
Bontrager Line Pro, Knock Block, 35mm clamp, 0 degree
Handlebar
Bontrager Line Pro, OCLV Carbon, 35mm, 15mm rise, 750mm width
Grips
Bontrager XR Trail Elite, alloy lock-on
Headset
Knock Block Integrated, sealed cartridge bearing, 1-1/8? top, 1.5? bottom
Seat
Saddle
Bontrager Arvada Pro, carbon rails
Seatpost
Bontrager Line, internal routing, 31.6mm, 15.5: 100mm, 17.5 & 18.5: 125mm, 19.5 & 21.5: 150mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM High | SM Low | MD High | MD Low | MD/LG High | MD/LG Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.52 mm | 1.57 mm | 1.4 mm | 1.44 mm | 1.34 mm | 1.38 mm | 1.3 mm | 1.33 mm | 1.26 mm | 1.29 mm |
| Bottom Bracket Height | 344 mm | 335 mm | 344 mm | 335 mm | 344 mm | 335 mm | 344 mm | 335 mm | 344 mm | 335 mm |
| Front Center | 691 mm | 690 mm | 726 mm | 725 mm | 743 mm | 742 mm | 758 mm | 757 mm | 784 mm | 783 mm |
| Rake | 51 mm | 51 mm | 53 mm | 51 mm | 53 mm | 51 mm | 53 mm | 51 mm | 53 mm | 52 mm |
| Trail | 99 mm | 103 mm | 99 mm | 103 mm | 99 mm | 103 mm | 99 mm | 103 mm | 99 mm | 103 mm |
| Stack | 598 mm | 603 mm | 597 mm | 603 mm | 597 mm | 603 mm | 597 mm | 603 mm | 606 mm | 612 mm |
| Reach | 393 mm | 385 mm | 427 mm | 420 mm | 444 mm | 437 mm | 459 mm | 452 mm | 481 mm | 474 mm |
| Top Tube Length | 559 mm | 560 mm | 593 mm | 595 mm | 610 mm | 612 mm | 625 mm | 627 mm | 651 mm | 651 mm |
| Seat Tube Angle | 74.7 ° | 74 ° | 74.7 ° | 74 ° | 74.7 ° | 74 ° | 74.7 ° | 74 ° | 74.7 ° | 74 ° |
| Seat Tube Length | 394 mm | 394 mm | 419 mm | 419 mm | 440 mm | 440 mm | 470 mm | 470 mm | 510 mm | 510 mm |
| Head Tube Angle | 67.7 ° | 67 ° | 67.7 ° | 67 ° | 67.7 ° | 67 ° | 67.7 ° | 67 ° | 67.7 ° | 67 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 110 mm | 110 mm |
| Chainstay Length | 426 mm | 429 mm | 426 mm | 429 mm | 426 mm | 429 mm | 426 mm | 429 mm | 426 mm | 429 mm |
| Wheelbase | 1115 mm | 1116 mm | 1150 mm | 1151 mm | 1167 mm | 1168 mm | 1182 mm | 1183 mm | 1208 mm | 1209 mm |
| Bottom Bracket Drop | 30 mm | 39 mm | 30 mm | 39 mm | 30 mm | 39 mm | 30 mm | 39 mm | 30 mm | 39 mm |
| Standover Height | 761 mm | 754 mm | 741 mm | 734 mm | 736 mm | 729 mm | 731 mm | 724 mm | 741 mm | 734 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
About this model
Fuel EX 9.9 29 is a Trek Fuel model. There are 277 bikes that carry this model name. You can easily view all of the Trek Fuel bikes models from 2019, here.
Model range prices
The most economical model, the Trek Fuel EX 5 29 2019 has a starting price of 1999$. Trek Fuel EX 9.9 29 2019 on the other hand is the most expensive at 7799$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Trail bikes
According to our math, the average price for a trustworthy Trail bike is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
This bike was released in 2019 and its price was 7799$. If we compare this with the average Trail bike cost we notice that the price is 182.37% more expensive.
Average weight for Trail bikes
Trail bikes have an average weight of 12.98 kg (28.62 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 12.19 kg (26.87 lbs), the Fuel EX 9.9 29 model is a bit lighter than average. In other words, this model is 6.48% lighter than the average Trail bike.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This bike has the Fox Factory Float 34 fork installed. The fork’s travel is 130mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Rear Shock
The shock that’s installed on this bike is FOX Factory Float EVOL, with a travel distance of 130mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, a full-suspension bike will give you the smoothest ride possible.
Wheels size
When it comes to wheels, the Fuel EX 9.9 29 bike is equipped with the 29″ carbon model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, these wheels are not ideal for smaller people.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, these are ideal for anyone.
Dropper post
Every bike should have a dropper post, and this one does. A dropper post is a must-have these days if you’re riding anything remotely technical. The main benefit of a dropper post is increased safety while riding. As mentioned above, the lever system allows you to quickly move the saddle out of the way when approaching descents or trail obstacles.
