Trek Fuel EX 9.9 X01 AXS 2020
2020 Mountain
Estimate price |
8,999$
Weight | 12.97 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 27.5" / 29" -
Travel Front 140mm -
Travel Rear 130mm -
Fork Fox Factory Float 36
-
Groupset X01 Eagle AXS -
Suspension Full -
Drivetrain Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV Mountain Carbon main frame & stays, internal storage, tapered head tube, Knock Block, Control Freak internal routing, Carbon Armor, ISCG 05, magnesium rocker link, Mino Link, ABP, Boost148, 130mm travel
Suspension Fork
Fox Factory 36, Float EVOL air spring, GRIP2 damper, tapered steerer, 44mm offset, Kashima Coat, Boost110, 15mm bolt-on axle, 140mm travel
Rear Shock
Size: XS, S, Fox Factory Float EVOL, RE:aktiv with Thru Shaft 3-position damper, Kashima Coat, tuned by Trek Suspension Lab, 210x52.5mm; Size: S, ML, L, M, XL, Fox Factory Float EVOL, RE:aktiv with Thru Shaft 3-position damper, Kashima Coat, tuned by Trek Suspension Lab, 210x55mm
Drivetrain
Rear Derailleur
SRAM X01 Eagle AXS
Shift Levers
SRAM Eagle AXS, wireless, 12-speed
Crank
Size: XS, S, SRAM X01 Eagle AXS Carbon, DUB, 32T alloy ring, Boost (52mm chainline), 170mm length; Size: ML, L, M, XL, SRAM X01 Eagle AXS Carbon, DUB, 32T alloy ring, Boost (52mm chainline), 175mm length
Bottom Bracket
SRAM DUB, 92mm, PressFit
Chain
SRAM XX1 Eagle, 12 speed
Wheels
Rims
Bontrager Line Carbon 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle
Tires
Size: XS, S, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 27.5x2.60''; Size: S, ML, L, M, XL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120 tpi, 29x2.60''
Brakes
Brakes
Shimano XT M8120 4-piston hydraulic disc
Disk Rotors
Size: XS, S, ML, L, M, XL, Shimano RT76, 180mm, 6-bolt; Size: XS, S, ML, L, M, XL, Shimano RT76, 203mm, 6-bolt
Cockpit
Stem
Size: XS, S, Bontrager Line Pro, 35mm, Knock Block, 0 degree, 40mm length; Size: ML, L, M, XL, Bontrager Line Pro, 35mm, Knock Block, 0 degree, 50mm length
Handlebar
Bontrager Line Pro, OCLV Carbon, 35mm, 27.5mm rise, 780mm width
Grips
Bontrager XR Trail Elite, alloy lock-on
Headset
Knock Block Integrated, 58-degree radius, cartridge bearing, 1-1/8'' top, 1.5'' bottom
Seat
Saddle
Bontrager Arvada, austenite rails, 138mm width
Seatpost
Size: XS, S, RockShox Reverb AXS, 100mm travel, wireless, 31.6mm, 340mm length; Size: ML, M, RockShox Reverb AXS, 150mm travel, wireless, 31.6mm, 440mm length; Size: L, XL, RockShox Reverb AXS, 170mm travel, wireless, 31.6mm, 480mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS High | XS Low | SM High | SM Low | SM High | SM Low | MD High | MD Low | MD/LG High | MD/LG Low | LG High | LG Low | XL High | XL Low |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.39 mm | 1.42 mm | 1.35 mm | 1.37 mm | 1.43 mm | 1.46 mm | 1.35 mm | 1.38 mm | 1.32 mm | 1.34 mm | 1.28 mm | 1.3 mm | 1.24 mm | 1.26 mm |
| Bottom Bracket Height | 341 mm | 335 mm | 341 mm | 335 mm | 346 mm | 339 mm | 346 mm | 339 mm | 346 mm | 339 mm | 346 mm | 339 mm | 346 mm | 339 mm |
| Front Center | 684 mm | 684 mm | 708 mm | 708 mm | 719 mm | 719 mm | 744 mm | 744 mm | 761 mm | 761 mm | 776 mm | 776 mm | 807 mm | 807 mm |
| Rake | 43 mm | 43 mm | 43 mm | 43 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 43 mm | 44 mm | 43 mm | 44 mm | 43 mm |
| Trail | 107 mm | 111 mm | 108 mm | 111 mm | 115 mm | 119 mm | 116 mm | 119 mm | 116 mm | 119 mm | 116 mm | 119 mm | 116 mm | 119 mm |
| Stack | 565 mm | 569 mm | 574 mm | 578 mm | 611 mm | 614 mm | 611 mm | 614 mm | 615 mm | 619 mm | 615 mm | 619 mm | 629 mm | 633 mm |
| Reach | 406 mm | 401 mm | 426 mm | 421 mm | 426 mm | 421 mm | 451 mm | 446 mm | 466 mm | 461 mm | 481 mm | 476 mm | 506 mm | 501 mm |
| Top Tube Length | 551 mm | 556 mm | 573 mm | 574 mm | 583 mm | 584 mm | 608 mm | 609 mm | 624 mm | 625 mm | 639 mm | 640 mm | 667 mm | 669 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° | 75.5 ° | 75 ° |
| Seat Tube Length | 355 mm | 356 mm | 355 mm | 395 mm | 395 mm | 395 mm | 420 mm | 420 mm | 435 mm | 435 mm | 450 mm | 450 mm | 500 mm | 500 mm |
| Head Tube Angle | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° | 66.5 ° | 66 ° |
| Head Tube Length | 90 mm | 90 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 100 mm | 105 mm | 105 mm | 105 mm | 105 mm | 120 mm | 120 mm |
| Chainstay Length | 441 mm | 443 mm | 441 mm | 443 mm | 441 mm | 443 mm | 441 mm | 443 mm | 441 mm | 443 mm | 441 mm | 443 mm | 441 mm | 443 mm |
| Wheelbase | 1125 mm | 1126 mm | 1149 mm | 1150 mm | 1159 mm | 1160 mm | 1184 mm | 1185 mm | 1201 mm | 1202 mm | 1216 mm | 1217 mm | 1247 mm | 1248 mm |
| Bottom Bracket Drop | 14 mm | 21 mm | 14 mm | 21 mm | 28 mm | 34 mm | 28 mm | 34 mm | 27 mm | 34 mm | 27 mm | 34 mm | 27 mm | 34 mm |
| Standover Height | 706 mm | 701 mm | 713 mm | 708 mm | 713 mm | 708 mm | 753 mm | 747 mm | 758 mm | 752 mm | 760 mm | 754 mm | 782 mm | 776 mm |
| Wheels | 27" | 27" | 27" | 27" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
Model Overview
Fuel EX 9.9 X01 AXS is part of the Trek Fuel model. There are 277 bikes that carry this model name. You can easily view all of the Trek Fuel bikes models from 2020, here.
Model range prices
Trek Fuel EX 5 2020 is the most economical model, with a starting price of 2099$. Trek Fuel EX 9.9 X01 AXS 2020 on the other hand costs 8999$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Trail bikes
If you want an acceptable Trail bike you should know that the average price is 2762$. However, even if your budget is less than the average, you might still be able to get a top-quality Trail bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 8999$. Comparing this to the average Trail bike price, we see that the price is 225.81% higher.
Trail bikes average weight
Trail bikes weigh an average of 12.98 kg (28.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Fuel EX 9.9 X01 AXS weighs 12.97 kg (28.59 lbs) and is slightly lighter than the average. In conclusion, the average Trail bike weighs 0.08% more than Fuel EX 9.9 X01 AXS.
Internal Cable Routing
Moreover, this bike comes with internal cable routing allowing you to keep the cables in a good condition. It also makes it look more professional.
Overview of components
Fork
This bike has the Fox Factory Float 36 fork installed. The fork’s travel is 140mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
The shock that’s installed on this bike is Size: XS, with a travel distance of 130mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. In short, if you want smooth rides, get a full-suspension bicycle.
Wheels
The wheels on Fuel EX 9.9 X01 AXS are the 27.5″ carbon type. The 27.5″ wheels are a great choice for smaller riders. However, the 27.5″ wheels are less forgiving than the 29″ wheels.
Brakes
We ride faster and faster, so a good braking system is essential on a bike nowadays. The Fuel EX 9.9 X01 AXS comes with Hydraulic Disc brakes. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
Dropper post
The Trek model is also equipped with a dropper post. If you are a technical rider, a dropper post is essential. A dropper post provides increased safety while riding. The lever system, allows you to move your saddle up and down, which is very useful on climbs and descends.
