Trek FX 1 Stagger 2020
2020 Urban
Estimate price |
439$
Weight | 12.33 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Altus, Tourney -
Suspension Rigid -
Drivetrain 3 × 7 -
Brakes Rim
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
LG
174cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Gold Aluminum, stagger top tube, rack & fender mounts, DuoTrap S compatible, cantilever brake mount, 135x5mm QR
Suspension Fork
FX Steel, threadless steel steerer, rack mounts, cantilever brake mount, 405mm axle-to-crown, 5x100mm QR
Drivetrain
Rear Derailleur
Shimano Altus M310
Front Derailleur
Shimano Tourney TY510, 34.9mm clamp, top swing, dual pull
Shift Levers
Shimano Altus EF500, 7 speed
Cassette
SunRace MFM300 freewheel, 14-34, 7 speed
Crank
Forged alloy, 48/38/28, chainguard, 170mm length
Bottom Bracket
VP BC73, 68mm, threaded
Chain
KMC Z7
Wheels
Front Hub
Formula FM21 alloy, 100x5mm QR
Rear Hub
Formula FM31 alloy, 135x5mm QR
Rims
Bontrager Connection, alloy, double-wall, 32-hole, schrader valve
Tires
Bontrager H2, wire bead, 30 tpi, 700x35c
Brakes
Brakes
Tektro alloy linear-pull
Cockpit
Stem
Bontrager alloy, 25.4mm clamp, 10 degree, 90mm length
Handlebar
Bontrager Riser, steel, 25.4mm, 30mm rise, 600mm width
Grips
Bontrager Satellite
Headset
1-1/8'' threadless, sealed cartridge bearings
Seat
Saddle
Bontrager Sport Women's
Seatpost
Bontrager alloy, 27.2mm, 12mm offset, 330mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.43 mm | 1.5 mm | 1.53 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm |
| Front Center | 619 mm | 620 mm | 620 mm |
| Rake | 50 mm | 50 mm | 45 mm |
| Trail | 71 mm | 71 mm | 70 mm |
| Stack | 553 mm | 572 mm | 596 mm |
| Reach | 387 mm | 381 mm | 389 mm |
| Top Tube Length | 541 mm | 546 mm | 566 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° |
| Seat Tube Length | 381 mm | 445 mm | 508 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° |
| Head Tube Length | 130 mm | 150 mm | 170 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1054 mm | 1055 mm | 1055 mm |
| Bottom Bracket Drop | 65 mm | 65 mm | 65 mm |
| Standover Height | 625 mm | 630 mm | 634 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 155 cm | 164 cm | 174 cm |
| Rider Max Height | 166 cm | 176 cm | 186 cm |
Model Overview
FX 1 Stagger is part of the Trek Fx model. 128 bikes variations carry this model name so far. Take a sneak peek at all Trek Fx bikes models from 2020, by clicking here.
Model range prices
The most economical model, the Trek FX 1 Stagger 2020 has a starting price of 439$. Trek FX Sport 6 2020 on the other hand is the most expensive at 2099$.
Safety
Your safety is a top priority so always wear a helmet when you ride your bike. Moreover, wear the right clothing. You want to be visible to other drivers, so avoid wearing dark clothing.
Average price for Fitness bikes
If you want to purchase a solid Fitness bike, it is important to know that the average cost is 656$. However, even if your budget is less than the average, you might still be able to get a top-quality Fitness bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 439$. In conclusion, this bike price is 49.43% smaller than the price of the average Fitness bike.
Average weight for Fitness bikes
Fitness bikes weigh an average of 11.24 kg (24.78 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
a bit heavier than average, FX 1 Stagger has a weight of 12.33 kg (27.18 lbs). In short, the average Fitness bike weight is 9.7% lower than this one.
Overview of components
Fork material
The fork is made out of steel, which tends to be more flexible than carbon forks in general. However, a carbon fork is considerably lighter.
Wheels
The FX 1 Stagger 2020 bike is equipped with 700c aluminum wheels when leaving the factory. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Trek FX 1 Stagger bike has 3 sizes, in the range of 155 cm – 186 cm (5.09 ft – 6.1 ft). In short, it won’t be difficult to find the right one for you.
