Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 700c -
Groupset Alivio, Acera -
Suspension Rigid -
Drivetrain 3 × 9 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
FX Alpha Gold Aluminum, DuoTrap S compatible, rack & fender mounts
Suspension Fork
Bontrager Nebula, carbon
Drivetrain
Rear Derailleur
Shimano Alivio T4000
Front Derailleur
Shimano Acera
Shift Levers
Shimano EF65, 9 speed
Cassette
Shimano HG20, 11-34, 9 speed
Crank
Shimano Acera M371, 48/36/26 w/chainguard
Bottom Bracket
Sealed cartridge
Chain
KMC X9
Pedals
Wellgo nylon body w/alloy cage
Wheels
Front Hub
Formula FM21 alloy
Rear Hub
Alloy
Rims
Bontrager Tubeless Ready, 32h
Tires
Bontrager H2 Hard-case Lite, 700x32c
Brakes
Brakes
Tektro alloy linear-pull
Cockpit
Stem
Bontrager Elite, 31.8mm, 7 degree, w/computer & light mounts
Handlebar
Bontrager Satellite Plus IsoZone, 31.8mm, 15mm rise
Grips
Bontrager Satellite IsoZone Plus, lock-on, ergonomic
Headset
1-1/8? threadless, sealed cartridge bearings
Seat
Saddle
Bontrager H1
Seatpost
Bontrager SSR, 2-bolt head, 27.2mm, 12mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15" | 17.5" | 20" | 22.5" | 25" |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.38 mm | 1.43 mm | 1.5 mm | 1.56 mm | 1.66 mm |
| Bottom Bracket Height | 285 mm | 285 mm | 285 mm | 285 mm | 285 mm |
| Front Center | 619 mm | 619 mm | 620 mm | 626 mm | 627 mm |
| Rake | 50 mm | 50 mm | 45 mm | 45 mm | 45 mm |
| Trail | 70 mm | 70 mm | 70 mm | 62 mm | 62 mm |
| Stack | 539 mm | 553 mm | 587 mm | 619 mm | 648 mm |
| Reach | 392 mm | 387 mm | 392 mm | 398 mm | 390 mm |
| Top Tube Length | 542 mm | 546 mm | 566 mm | 588 mm | 601 mm |
| Seat Tube Angle | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 72 ° |
| Seat Tube Length | 381 mm | 444 mm | 508 mm | 571 mm | 635 mm |
| Head Tube Angle | 70.5 ° | 70.5 ° | 71.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 115 mm | 130 mm | 160 mm | 190 mm | 220 mm |
| Chainstay Length | 443 mm | 443 mm | 443 mm | 443 mm | 443 mm |
| Wheelbase | 1055 mm | 1055 mm | 1056 mm | 1062 mm | 1063 mm |
| Bottom Bracket Drop | 62 mm | 62 mm | 62 mm | 62 mm | 62 mm |
| Standover Height | 691 mm | 733 mm | 781 mm | 829 mm | 875 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
About this model
FX 3 is a Trek Fx model. Trek launched 128 bikes of this model so far. Check out the entire range from 2018 of this model, by clicking this link.
Model range prices
Trek FX 2018 is the cheapest bike model and costs 359$. Trek FX S 6 2018 is the most expensive one and costs 2099$.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Average price for Fitness bikes
According to our calculations, the average cost of a Fitness bike that is reliable is 656$. However, this doesn’t mean that if you spend less money on a Fitness bike, you couldn’t get a decent one. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, this bike was made available in 2018 for 659$. Comparing the average cost of a Fitness bike to this one, you will see that FX 3 price is 0.46% more expensive.
Average weight for Fitness bikes
The average weight for Fitness bikes is 11.24 kg (24.78 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
With a weight of 11.17 kg (24.63 lbs), Trek bike is slightly lighter than average. To sum up, it’s 0.63% lighter than the average weight of Fitness bikes.
FX 3 components
Fork material
The fork is made out of carbon, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the FX 3 model has 700c aluminum wheels. There is no doubt, that 700c wheels are very popular on all road bike models. However, while they give you great speed and control, these wheels are not so bump-friendly.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek FX 3 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they are not nearly as effective as hydraulic brakes are.
