Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 26" -
Groupset Alivio, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha White Aluminum
Drivetrain
Rear Derailleur
Shimano Alivio
Front Derailleur
Shimano M191
Shift Levers
Shimano EF60, 8-speed trigger
Cassette
SRAM PG-830 11-32, 8 speed
Crank
Shimano M171, 48/38/28 w/chainguard
Pedals
Alloy platform w/Kraton inserts
Wheels
Rims
Shimano RM60 rear hub, alloy front hub; Bontrager Camino 36-hole alloy rims
Tires
Bontrager H2 Hard-Case, 26x2.0"
Brakes
Brakes
Tektro V-brakes w/EF60 levers
Cockpit
Stem
Alloy, adjustable rise
Handlebar
Alloy, 80mm rise
Headset
Threaded, semi-cartridge bearings, sealed
Seat
Saddle
Bontrager Suburbia w/gel padding
Seatpost
Alloy, adjustable suspension
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 14.5" | 16.5" | 18.5" | 21" |
|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" |
Model Overview
Navigator 3.0 belongs to the Trek Navigator model. 66 bikes variations carry this model name so far. Check out the entire range from 2011 of this model, by clicking this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Comfort bikes average price
According to our calculations, the average cost of a Comfort bike that is reliable is 360$. However, you could also get a good Comfort bike even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the bike and its components before buying it to ensure you don’t pay too much.
Overview of components
Wheels
When leaving the production line, the Navigator 3.0 model has 26″ aluminum wheels. Being a little smaller, these wheels will fit both small and tall riders. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek Navigator 3.0 has Rim brakes installed. Rim brakes are cheaper than hydraulic brakes, and also easier to maintain. However, they have problems in wet conditions.
