Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Shimano -
Suspension Rigid -
Drivetrain 3 × 10 -
Brakes Rim
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
OCLV 120 Carbon
Suspension Fork
Bontrager Race X Lite Plus w/BzzzKill, carbon
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra
Shift Levers
Shimano ST-R700 STI, adjustable reach, 10 speed
Cassette
Shimano Ultegra 12-25, 10 speed
Crank
Shimano Ultegra 52/39/30
Pedals
n/a
Wheels
Rims
Bontrager Race Lite
Tires
Bontrager Race X Lite AC, folding, 700x25c
Brakes
Brakes
Shimano R600 long reach w/adjustable reach STI levers
Cockpit
Stem
Bontrager Race Lite, 17 degree, 31.8mm
Handlebar
Bontrager Race Lite w/BzzzKill, 31.8mm
Headset
Aheadset Slimstak w/cartridge bearings, sealed, alloy
Seat
Saddle
Bontrager Race Lux FIT
Seatpost
Bontrager Race X Lite ACC Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 47cm | 50cm | 54cm | 57cm |
|---|---|---|---|---|
| Wheels | 700 | 700 | 700 | 700 |
About this model
Pilot 5.2 s.p.a. WSD is part of the Trek Pilot model. Trek released 45 bikes variations of this model so far. You can get a glimpse at all models from 2006, by clicking on this link.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Endurance bikes
According to our calculations, the average cost of an Endurance bike that is reliable is 2346$. However, you could also get a good Endurance bike even if you pay a lower amount than the average price. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it won’t add up to much weight to your bike. However, the price you have to pay for a carbon fork is considerably higher.
Wheels size
When it comes to wheels, the Pilot 5.2 s.p.a. WSD bike is equipped with the 700c aluminum model. There is no doubt, that 700c wheels are very popular on all road bike models. However, these wheels don’t perform so well when passing over obstacles.
Brakes
Stopping the bike when needed, it’s essential for your safety. This bike has Rim brakes. Slightly lighter than hydraulic brakes, rim brakes are a budget choice. However, they have problems in wet conditions.
