Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Wheels 700c -
Groupset Ultegra, Dura-Ace -
Suspension Rigid -
Drivetrain 2 × 10 -
Brakes Rim
Sizing
Recommended size guide.
XS
151cm - 164cm
SM
160cm - 172cm
MD
166cm - 179cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
600 Series OCLV Carbon, KVF (Kammtail Virtual Foil) tube design, SC Speed Box & DuoTrap compatible, includes SC Draft Box
Suspension Fork
Bontrager SC, 600 Series OCLV Carbon, KVF leg design, integrated brake & stem
Drivetrain
Rear Derailleur
Shimano Ultegra
Front Derailleur
Shimano Ultegra, braze-on
Shift Levers
Shimano Dura-Ace, bar end control, 10 speed
Cassette
Shimano Ultegra 11-25, 10 speed
Crank
Shimano Ultegra, 53/39 (double)
Pedals
n/a
Wheels
Rims
Bontrager Race Lite (XS: Xero XR-200, 650c)
Tires
Bontrager R3, 700x23c (XS: Bontrager Race Lite, 650x25c)
Brakes
Brakes
Bontrager Speed Concept integrated brakes w/Bontrager Race Lite aero levers
Cockpit
Stem
Bontrager Speed Concept, direct mount
Handlebar
Bontrager Speed Concept aero bar w/ski bend extension, carbon, direct mount
Headset
Integrated, sealed bearings
Seat
Saddle
Fizik Vitesse Tri, manganese rails
Seatpost
Bontrager Speed Concept Race X Lite, carbon, +/-10mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 151 cm | 160 cm | 166 cm |
| Rider Max Height | 164 cm | 172 cm | 179 cm |
About this model
Speed Concept 9.5 WSD is part of the Trek Speed model. Trek launched 112 bikes of this model so far. Check out the entire range from 2012 of this model, by clicking this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Average price for Triathlon bikes
If you want to purchase a solid Triathlon bike, it is important to know that the average cost is 4177$. However, you could also get a good Triathlon bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Fork material
The fork on this bike is made out of carbon, so, it’s a great addition to the bike’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
Wheels
The wheels on Speed Concept 9.5 WSD are the 700c aluminum type. These wheels are the most used kind for road bikes in general. However, these wheels don’t perform so well when passing over obstacles.
Brakes
When you want to stop the bike in time, the brakes are vital. The Speed Concept 9.5 WSD has Rim brakes. Rim brakes deliver an average performance overall. However, they are not nearly as effective as hydraulic brakes are.
Sizes
Trek Speed Concept 9.5 WSD bike has 3 sizes, in the range of 151 cm – 179 cm (4.95 ft – 5.87 ft). In short, you can easily find one that suits you.
