Trek Supercaliber SLR Frameset 2024
2024 Mountain
Estimate price |
4,587$
Weight | 2 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
Category -
Frame Carbon -
Wheels 29" -
Travel Rear 80mm -
Suspension Full
Sizing
Recommended size guide.
SM
155cm - 166cm
MD
164cm - 176cm
MD/LG
173cm - 180cm
LG
177cm - 189cm
XL
187cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SLR OCLV Mountain Carbon, IsoStrut, UDH, 80 mm travel
Rear Shock
Trek IsoStrut, RockShox SIDLuxe, 2-position remote damper
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | MD/LG | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.36 mm | 1.31 mm | 1.29 mm | 1.25 mm |
| Bottom Bracket Height | 327 mm | 327 mm | 327 mm | 327 mm | 327 mm |
| Front Center | 682 mm | 707 mm | 722 mm | 741 mm | 786 mm |
| Rake | 42 mm | 42 mm | 42 mm | 42 mm | 42 mm |
| Trail | 109 mm | 109 mm | 109 mm | 109 mm | 109 mm |
| Stack | 585 mm | 585 mm | 585 mm | 594 mm | 617 mm |
| Reach | 405 mm | 430 mm | 445 mm | 460 mm | 495 mm |
| Top Tube Length | 566 mm | 587 mm | 600 mm | 617 mm | 658 mm |
| Seat Tube Angle | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° | 74.5 ° |
| Seat Tube Length | 395 mm | 420 mm | 440 mm | 460 mm | 525 mm |
| Head Tube Angle | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° | 67.5 ° |
| Head Tube Length | 90 mm | 90 mm | 90 mm | 100 mm | 125 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1108 mm | 1133 mm | 1148 mm | 1167 mm | 1212 mm |
| Bottom Bracket Drop | 46 mm | 46 mm | 46 mm | 46 mm | 46 mm |
| Standover Height | 755 mm | 767 mm | 767 mm | 767 mm | 767 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 155 cm | 164 cm | 173 cm | 177 cm | 187 cm |
| Rider Max Height | 166 cm | 176 cm | 180 cm | 189 cm | 195 cm |
Model Overview
Supercaliber SLR Frameset is part of the Trek Supercaliber model. 68 frames variations carry this model name so far. Check out the entire range from 2024 of this model, by clicking this link.
Model range prices
The most economical model, the Trek Supercaliber SLR Gen 2 Frameset 2024 has a starting price of 3999$. Trek Supercaliber SLR Frameset 2024 on the other hand is the most expensive at 4246$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Crosscountry frames
Our math shows that the average cost of a dependable Crosscountry frame is 1689$. However, even if your budget is less than the average, you might still be able to get a top-quality Crosscountry frame. To sum up, when you purchase your frame, make sure to check if it has reviews, and also do some components research.
At the moment of the release date, Trek Supercaliber SLR Frameset price was 4246$. Comparing this to the average Crosscountry frame price, we see that the price is 151.39% higher.
Crosscountry frames average weight
On a deeper look, we notice that the average weight of a Crosscountry frame is 1.98 kg (4.37 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Weighing 2 kg (4.41 lbs), the Supercaliber SLR Frameset model is slightly heavier than average. In short, the average Crosscountry frame weight is 1.01% lower than this one.
Supercaliber SLR Frameset components
Rear Shock
Trek Supercaliber SLR Frameset frame has the Trek IsoStrut model installed, and has a travel of 80mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. To sum up, always consider getting a bike that has a rear shock as well.
Sizes
This frame is available in 5 sizes. They vary from 155 cm – 195 cm (5.09 ft – 6.4 ft). In short, it won’t be difficult to find the right one for you.
