Trek Ticket S Frameset 2023
2023 Mountain
Estimate price |
1,899$
Weight | 3.08 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Aluminum -
Wheels 26" -
Travel Rear 100mm -
Suspension Full
Sizing
Recommended size guide.
LG High
175cm - 186cm
LG Low
175cm - 186cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Platinum Aluminum, tapered head tube, alloy rocker link, press fit BB, ISCG 05, Mino Link, 100mm travel
Rear Shock
Fox Performance Float SV, 3-position damper, 6.5x1.5''
Cockpit
Headset
FSA Orbit, sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | LG High | LG Low |
|---|---|---|
| Stack Reach Ratio | 1.26 mm | 1.28 mm |
| Bottom Bracket Height | 339 mm | 330 mm |
| Front Center | 685 mm | 685 mm |
| Rake | 45 mm | 42 mm |
| Trail | 88 mm | 88 mm |
| Stack | 546 mm | 546 mm |
| Reach | 432 mm | 425 mm |
| Top Tube Length | 562 mm | 564 mm |
| Seat Tube Angle | 75.8 ° | 75 ° |
| Seat Tube Length | 331 mm | 331 mm |
| Head Tube Angle | 69.3 ° | 68.5 ° |
| Head Tube Length | 123 mm | 123 mm |
| Chainstay Length | 397 mm | 399 mm |
| Wheelbase | 1082 mm | 1084 mm |
| Bottom Bracket Drop | 6 mm | 3 mm |
| Standover Height | 382 mm | 374 mm |
| Wheels | 26" | 26" |
| Rider Min Height | 175 cm | 175 cm |
| Rider Max Height | 186 cm | 186 cm |
Model Overview
Ticket S Frameset is a Trek Ticket model. Trek released 42 frames variations of this model so far. Check out the entire range from 2023 of this model, by clicking this link.
Model range prices
Trek Ticket DJ Frameset 2023 is the most economical model, with a starting price of 949$. Trek Ticket S Frameset 2023 on the other hand costs 1899$, and is the most expensive model.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Dirt Jump frames
According to our calculations, the average cost of a Dirt Jump frame that is reliable is 491$. However, even though the average price of a Dirt Jump frame is lower, you might still be able to get a top-quality frame. In conclusion, always check frame reviews and their components before making a purchase to make sure you don’t overpay.
This frame was released in 2023 and its price was 1899$. Comparing this to the average Dirt Jump frame price, we see that the price is 286.76% higher.
Dirt Jump frames average weight
Dirt Jump frames weigh an average of 2.7 kg (5.95 lbs). You will have a greater advantage on climbs if your bike is easier than the average. On descents, however, a heavier bike will give you extra speed.
Ticket S Frameset weighs 3.08 kg (6.79 lbs) and is considerably heavier than the average. To sum up, it’s 14.07% heavier than the average weight of Dirt Jump frames.
Ticket S Frameset components
Rear Shock
The shock that’s installed on this frame is Fox Performance Float SV, with a travel distance of 100mm. Bike rear shocks are a great way to increase comfort on the bike and give you more control when riding on technical trails. In short, if you want smooth rides, get a full-suspension bicycle.
Sizes
This frame is available in 2 sizes. They vary from 175 cm – 186 cm (5.74 ft – 6.1 ft). In short, you can easily find one that suits you.
