Trek Top Fuel 5 2023
2023 Mountain
Estimate price |
2,699$
Weight | 15.29 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 120mm -
Travel Rear 120mm -
Fork RockShox Recon Silver RL
-
Groupset Deore, Shimano -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Alpha Platinum Aluminum, internal storage, tapered head tube, Knock Block 2.0, internal guided routing, downtube guard, magnesium rocker link, Mino Link, ABP, Boost148, 120mm travel
Suspension Fork
RockShox Recon Silver RL, Solo Air, Motion Control damper, lockout, tapered steerer, 42mm offset, Boost110, 15mm Maxle Stealth, 120mm travel
Rear Shock
X-Fusion Pro 2, 2-position damper, 185mm x 50mm
Drivetrain
Rear Derailleur
Shimano Deore M6100, long cage
Shift Levers
Shimano Deore M6100, 12 speed
Cassette
Shimano Deore M6100, 10-51, 12 speed
Crank
Size: S, M, M/L, L, Shimano MT512, 30T ring, 55mm chainline, 170mm length; Size: XL, XXL, Shimano MT512, 30T ring, 55mm chainline, 175mm length
Bottom Bracket
Size: S, M, M/L, L, XL, XXL, Shimano BB-MT501 BSA; Size: S, M, M/L, L, XL, XXL, Shimano SM-BB52, 73mm, threaded external bearing
Chain
Shimano Deore M6100, 12 speed
Wheels
Front Hub
Bontrager alloy, 6-bolt, Boost110, 15mm thru axle
Rear Hub
Bontrager alloy, sealed bearing, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle
Rims
Alex MD35, tubeless compatible, 32-hole, 35mm width, Presta valve
Tires
Size: S, M, M/L, L, XL, XXL, Bontrager XT3 Elite, wire bead, 60 tpi, 29x2.40''; Size: S, M, M/L, L, XL, XXL, Bontrager XR4 Team Issue, Tubeless Ready, Inner Strength sidewalls, aramid bead, 120tpi, 29x2.40''
Brakes
Brakes
Shimano MT200 hydraulic disc
Cockpit
Stem
Bontrager Rhythm Comp, 31.8mm, Knock Block, 0 degree, 50mm length
Handlebar
Size: S, M, M/L, L, XL, XXL, Bontrager alloy, 31.8mm, 15mm rise, 750mm width; Size: S, M, M/L, L, XL, XXL, Bontrager Rhythm Comp, alloy, 31.8mm, 15mm rise, 750mm width
Grips
Bontrager XR Trail Comp, nylon lock-on
Headset
Knock Block 2.0 Integrated, 72-degree radius (includes infinite-radius chip), sealed cartridge bearing, 1-1/8'' top, 1.5'' bottom
Seat
Saddle
Bontrager Arvada, steel rails, 138mm width
Seatpost
Size: S, TranzX JD-YSI-22PLQ, 100mm travel, internal routing, 34.9mm, 346mm length; Size: M, M/L, TranzX JD-YSI-22PLQ, 150mm travel, internal routing, 34.9mm, 454mm length; Size: L, XL, XXL, TranzX JD-YSI-22PLQ, 170mm travel, internal routing, 34.9mm, 497mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 15.5" High | 15.5" Low | 17.5" High | 17.5" Low | 18.5" High | 18.5" Low | 19.5" High | 19.5" Low | 21.5" High | 21.5" Low | 23" High | 23" Low |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.4 mm | 1.42 mm | 1.31 mm | 1.33 mm | 1.28 mm | 1.29 mm | 1.24 mm | 1.26 mm | 1.22 mm | 1.24 mm | 1.19 mm | 1.21 mm |
| Bottom Bracket Height | 343 mm | 338 mm | 343 mm | 338 mm | 343 mm | 338 mm | 343 mm | 338 mm | 343 mm | 338 mm | 343 mm | 338 mm |
| Front Center | 718 mm | 718 mm | 748 mm | 748 mm | 765 mm | 765 mm | 782 mm | 782 mm | 808 mm | 808 mm | 833 mm | 832 mm |
| Rake | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm | 44 mm |
| Trail | 115 mm | 118 mm | 115 mm | 118 mm | 115 mm | 118 mm | 115 mm | 118 mm | 115 mm | 118 mm | 115 mm | 118 mm |
| Stack | 587 mm | 590 mm | 587 mm | 590 mm | 592 mm | 595 mm | 596 mm | 600 mm | 610 mm | 613 mm | 619 mm | 622 mm |
| Reach | 419 mm | 415 mm | 449 mm | 445 mm | 464 mm | 460 mm | 479 mm | 475 mm | 499 mm | 495 mm | 519 mm | 515 mm |
| Top Tube Length | 562 mm | 563 mm | 592 mm | 593 mm | 609 mm | 610 mm | 625 mm | 626 mm | 648 mm | 649 mm | 670 mm | 671 mm |
| Seat Tube Angle | 76.4 ° | 76 ° | 76.4 ° | 76 ° | 76.4 ° | 76 ° | 76.4 ° | 76 ° | 76.4 ° | 76 ° | 76.4 ° | 76 ° |
| Seat Tube Length | 395 mm | 395 mm | 420 mm | 420 mm | 435 mm | 435 mm | 450 mm | 450 mm | 500 mm | 500 mm | 540 mm | 540 mm |
| Head Tube Angle | 66.4 ° | 66 ° | 66.4 ° | 66 ° | 66.4 ° | 66 ° | 66.4 ° | 66 ° | 66.4 ° | 66 ° | 66.4 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 100 mm | 100 mm | 105 mm | 105 mm | 110 mm | 110 mm | 125 mm | 125 mm | 135 mm | 135 mm |
| Chainstay Length | 429 mm | 430 mm | 429 mm | 430 mm | 429 mm | 430 mm | 429 mm | 430 mm | 429 mm | 430 mm | 429 mm | 430 mm |
| Wheelbase | 1145 mm | 1146 mm | 1175 mm | 1176 mm | 1192 mm | 1193 mm | 1209 mm | 1210 mm | 1235 mm | 1236 mm | 1260 mm | 1260 mm |
| Bottom Bracket Drop | 31 mm | 36 mm | 31 mm | 36 mm | 31 mm | 36 mm | 31 mm | 36 mm | 31 mm | 36 mm | 30 mm | 36 mm |
| Standover Height | 714 mm | 710 mm | 735 mm | 730 mm | 740 mm | 735 mm | 745 mm | 740 mm | 755 mm | 750 mm | 765 mm | 760 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" | 29" |
About this model
Top Fuel 5 belongs to the Trek Top Fuel model. 123 bikes variations carry this model name so far. You can easily view all of the Trek Top Fuel bikes models from 2023, here.
Model range prices
Trek Top Fuel 5 2023 is the cheapest bike model and costs 2699$. Trek Top Fuel 9.9 XX1 AXS 2023 is the most expensive one and costs 11499$.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Trail bikes average price
Our math shows that the average cost of a dependable Trail bike is 2762$. However, you could also get a good Trail bike even if you pay a lower amount than the average price. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
This bike was released in 2023 and its price was 2699$. In conclusion, this bike price is 2.33% lower than the price of the average Trail bike.
Average weight for Trail bikes
On a deeper look, we notice that the average weight of a Trail bike is 12.88 kg (28.4 lbs). It is a good advantage to have a lighter bike than the average. However, a heavier bike is more efficient on descents.
Top Fuel 5 weighs 15.29 kg (33.71 lbs) and is much heavier than the average. In conclusion, the average Trail bike weighs 18.71% less than Top Fuel 5.
Internal Cable Routing
It’s also important to mention the internal cable routing that this bike has. In short, this will allow you to keep your bike cables in great condition. Say goodbye to hanging cables.
Top Fuel 5 components
Fork
This bike has the RockShox Recon Silver RL fork installed. The fork’s travel is 120mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. In short, make sure you choose one with a decent fork when you purchase your dream bike.
Rear Shock
From the factory, it comes with the X-Fusion Pro 2 rear shock model, which has a travel of 120mm. Rear shocks offer better comfort, better traction, and better cornering. This allows for quicker riding on rough roads and trails. To sum up, always consider getting a bike that has a rear shock as well.
Wheels
As for the wheels, Trek Top Fuel 5 2023, has a 29″ aluminum model. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, 29″ wheels will make your bike react slower to obstacles you may encounter.
Brakes
Nothing is more important on a bike than its ability to brake properly. Trek Top Fuel 5 is equipped with Hydraulic Disc brakes. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
Dropper post
A dropper post is included with the Top Fuel 5. Needless to say, a dropper post will come in handy on climbs and descends. You’ll fall in love with it at first sight!
