Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 26" -
Groupset X4, Altus -
Suspension Rigid -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
13"
156cm - 166cm
15.5"
163cm - 174cm
17.5"
171cm - 182cm
19"
179cm - 189cm
21"
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Gold Series 6061 T6 aluminum, G2 geometry, butted and hydroformed tubing, cold-forged dropouts & bottom bracket
Drivetrain
Rear Derailleur
SRAM X.4
Front Derailleur
Shimano Altus
Shift Levers
SRAM X.4, 8 speed
Cassette
SRAM PG-820 11-32, 8 speed
Crank
Shimano Acera, 42/32/22
Pedals
Wellgo ATB, boron axle, alloy cage
Wheels
Rims
Formula DC20 front hub, Shimano M475 rear hub; Bontrager Ranger Disc 32-hole rims
Tires
Bontrager Jones XR, 26x2.2/2.25"
Brakes
Brakes
Promax 907 hydraulic disc brakes, 6-bolt; 160mm rotors
Cockpit
Stem
Bontrager SSR
Handlebar
Bontrager Low Riser, 25mm rise, 9 degree sweep
Headset
1-1/8" threadless, semi-integrated, semi-cartridge bearings
Seat
Saddle
Bontrager Evoke 1
Seatpost
Bontrager SSR, 27.2mm, 20mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 13" | 15.5" | 17.5" | 19" | 21" |
|---|---|---|---|---|---|
| Wheels | 26" | 26" | 26" | 26" | 26" |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
Model Overview
Wahoo belongs to the Trek Wahoo model. Trek launched 37 bikes of this model so far. You can get a glimpse at all models from 2010, by clicking on this link.
Safety
When you go for a ride, don’t forget to put your helmet on. Moreover, ride with traffic, not against it. This will help you stay visible to drivers and also makes it easier for them to see you.
Crosscountry bikes average price
If you want an acceptable Crosscountry bike you should know that the average price is 1905$. However, this doesn’t mean that if you spend less money on a Crosscountry bike, you couldn’t get a decent one. In conclusion, always check bike reviews and their components before making a purchase to make sure you don’t overpay.
Overview of components
Wheels
The wheels on Wahoo are the 26″ aluminum type. The 26″ wheels are lighter than the 27.5 or 29″ wheels. However, they are less forgiving when riding over obstacles such as bumps and roots.
Brakes
For your safety, it is important to have quality breaks on your bike. Trek Wahoo has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, these are ideal for anyone.
Sizes
Trek Wahoo bike has 5 sizes, in the range of 156 cm – 195 cm (5.12 ft – 6.4 ft). In conclusion, it won’t take much to find one that’s right for you.
